GX1692U12 - 4P 2POS.FRN/MNTG KEY 22MM

Why Choose the GX1692U12?

The Lovato GX1692U12 is a GX series rotary cam ON/OFF switch designed for reliable 4‑pole, 16 A control. Product type designation GX16, it features the U12 front‑mounting format without front plate and key operation for Ø22 mm fixing. Its square‑shaped GX contact block architecture suits compact panels where positive isolation and straightforward ON/OFF action are essential.

With IP65 frontal protection and a rated impulse withstand voltage of 6 kV, this ON/OFF switch is engineered for demanding panel environments. It operates from -25 to +55 °C, stores between -40 and +70 °C, and conforms to IEC/EN/BS 60947-1, 60947-3, 60947-5-1, 61058-1, UL60947-4-1 and CSA C22.2 n° 14.

Key Benefits

• 4-pole, 16 A switching for clear ON/OFF isolation.
• IP65 frontal protection for robust, dust and water-resistant panels.
• Key-operated actuation supports controlled access to switching.
• U12 front mounting suits standard Ø22 mm panel cut-outs.
• GX16 designation within the GX square contact block series.
• 6 kV impulse withstand voltage for reliable insulation performance.
• Wide -25 to +55 °C operating temperature for varied environments.
• Conforms to IEC/EN/BS, UL and CSA standards for compliance.

Technical Specification

• Product type designation: GX16
• Rated impulse withstand voltage Uimp: 6 kV
• Operating temperature: -25 to +55 °C
• Storage temperature: -40 to +70 °C
• IP degree (frontal): IP65

What’s Included

• Lovato GX16 rotary cam ON/OFF switch, 4-pole 16 A
• Integrated key-operated actuator for Ø22 mm front mounting
• Downloadable datasheet and installation information
• Manufacturer packaging

Applications

• Main ON/OFF control in industrial and OEM panels
• 4-pole isolation in control and auxiliary circuits
• Panels with Ø22 mm cut-outs requiring key-operated switching
• HVAC, pumps and process equipment ON/OFF duties
• Electrical cabinets needing IP65 frontal protection

Safety note: Installation and operation must be performed by qualified personnel. Isolate power before work, follow applicable IEC/EN/BS 60947 requirements, and observe the product’s IP65, temperature, and 16 A limits.
