GLCMB0160T4E110 Lovato 4 Pole 160A 690V Motorised Changeover Switch
MPN: GLCMB0160T4E110
Special Price
£1,279.58
£1,066.32
Regular Price
£1,599.48
Why Choose the Lovato GLCMB0160T4E110 4‑Pole 160 A 690 V Motorised Changeover Switch?
The Lovato GLCMB0160T4E110 is a 4‑pole motorised changeover switch rated for 160 A at 690 V AC. Featuring a 110 V AC motor actuator, this device allows seamless remote switching between two independent power supplies with a central OFF position, ensuring full isolation of all phases and the neutral. Built to IEC 60947‑6‑1 and IEC 60947‑3 standards, it is a trusted solution for critical changeover applications such as automated transfer switches (ATS), generator panels, and emergency backup systems.
Technical Specifications
- Product Code: GLCMB0160T4E110
- Poles: 4 (three phases + neutral)
- Rated Current (Ith): 160 A
- Rated Operational Voltage (Ue): 690 V AC
- Motor Control Voltage: 110 V AC
- Switching Positions: I – 0 – II (Break-before-make)
- Standards Compliance: IEC 60947‑6‑1, IEC 60947‑3
- Operating Temperature: ‑25 °C to +70 °C
- Mounting Style: Panel or base-mounted
Key Features
- Full 4-pole isolation including neutral for safety-critical installations
- 110 V AC motor drive supports remote automation
- Mechanical I–0–II interlock guarantees safe changeover sequencing
- Compact footprint for use in crowded control cabinets
- Visible position indicators and padlock provision
Compatibility & Accessories
Fully compatible with Lovato ATL Series ATS controllers, door-coupled rotary handles, and IP-rated modular enclosures. Optional accessories include auxiliary contact blocks, mechanical interlocks, and protective shrouds for increased functionality and safety.
Frequently Asked Questions
- What current can the GLCMB0160T4E110 handle?
- How is the motorised changeover controlled remotely?
- Which international standards does it comply with?
- What control voltage is required for operation?
- Is the changeover switch IP rated?
- What are typical applications of this device?
Trusted by Customers Worldwide
"The GLCMB0160T4E110 has become our standard for 4‑pole ATS installations in remote switchgear rooms—dependable and precise." – Panel Design Specialist
This model supports up to 160 A, suitable for isolating medium-to-high load circuits in commercial and industrial settings.
The 110 V AC motor actuator receives commands from an ATS controller, relay logic, or PLC output for automated switching.
It meets IEC 60947‑6‑1 for transfer switching and IEC 60947‑3 for switch-disconnectors.
The motorised actuator operates with a 110 V AC input, compatible with standard industrial control supplies.
The device is designed for installation inside IP-rated enclosures (e.g., IP65, IP66) and does not carry a direct IP rating.
Commonly deployed in automatic transfer switch systems, generator backup panels, and main/standby source switching in mission-critical environments.
| Manufacturer Part Number | GLCMB0160T4E110 |
|---|---|
| Manufacturer | Lovato |
| Barcode | 8013975326725 |
| Number of Poles | 4 pole |
| Conditioned rated short-circuit current Iq | 100kA |
| Rated operation power at AC-23, 400 V | 90kW |
| Rated permanent current at AC-21, 400 V | 160A |
| Switching power at 400 V | 1280kW |
| Rated permanent current at AC-23, 400 V | 160A |
| Voltage | 690V |
| Maximum Continuous Voltage | 690V |
| Degree of protection (IP) | IP00 |
| Amperage | 160A |
| Type of electric connection | Screw connection |
| Packed Quantity | 1 |
| Height | 141mm |
| Width | 314mm |
| Depth | 191mm |
| Colour | Black |
