GLCMB0160T4D024 Lovato 4 Pole 160A 690V Motorised Changeover Switch
MPN: GLCMB0160T4D024
Special Price
£1,314.83
£1,095.69
Regular Price
£1,643.53
Why Choose the Lovato GLCMB0160T4D024 4‑Pole 160 A 690 V Motorised Changeover Switch?
The Lovato GLCMB0160T4D024 is a rugged 4‑pole motorised changeover switch, rated for 160 A at 690 V AC. Designed to switch between two power sources with a central OFF position, it supports complete phase and neutral isolation. The integrated 24 V DC motor actuator allows remote-controlled operation via ATS controllers or PLC systems. This switch is compliant with IEC 60947‑6‑1 and IEC 60947‑3, making it an ideal solution for critical infrastructure, industrial automation, and generator backup systems.
Technical Specifications
- Product Code: GLCMB0160T4D024
- Poles: 4 (three phase + neutral)
- Rated Current (Ith): 160 A
- Rated Operational Voltage (Ue): 690 V AC
- Motor Control Voltage: 24 V DC
- Switching Positions: I – 0 – II
- Standards Compliance: IEC 60947‑6‑1 (changeover), IEC 60947‑3 (disconnector)
- Mounting: Panel or base-mounted, compact frame
- Operating Temperature: ‑25 °C to +70 °C
Key Features
- 4‑pole design ensures full isolation of phase and neutral lines
- 24 V DC motorised actuator allows remote automation and control
- Break-before-make I–0–II switching for source separation
- Padlockable and visible contact indication for enhanced safety
- Compact dimensions support seamless integration into control panels
Compatibility & Accessories
This unit is fully compatible with Lovato's ATL automatic transfer controllers and PLC-driven logic. Accessories include door-coupling rotary handles, IP66 enclosures, mechanical interlocks, and auxiliary contacts for feedback signalling.
Frequently Asked Questions
- What current can the GLCMB0160T4D024 handle?
- How is the motorised changeover controlled remotely?
- Which international standards does it comply with?
- What control voltage is required for operation?
- Is the changeover switch IP rated?
- What are typical applications of this device?
Trusted by Customers Worldwide
"Installed the GLCMB0160T4D024 in our critical plant backup system—flawless remote switching and robust design." – Facilities Maintenance Engineer
This switch supports up to 160 A, making it suitable for medium-to-high load circuits with full phase and neutral isolation.
It uses a 24 V DC motor actuator that responds to ATS controller signals or programmable relay outputs for remote automation.
The switch complies with IEC 60947‑6‑1 and IEC 60947‑3, covering transfer switching equipment and switch-disconnectors.
It operates on 24 V DC, suitable for low-voltage control panels and PLC integration.
The device itself is not IP-rated but is designed to be mounted in IP65/IP66 enclosures for environmental protection.
Used in generator ATS panels, main/standby power switching, and industrial automation systems requiring remote changeover with full pole isolation.
| Manufacturer Part Number | GLCMB0160T4D024 |
|---|---|
| Manufacturer | Lovato |
| Barcode | 8013975326671 |
| Number of Poles | 4 pole |
| Conditioned rated short-circuit current Iq | 100kA |
| Rated operation power at AC-23, 400 V | 90kW |
| Rated permanent current at AC-21, 400 V | 160A |
| Switching power at 400 V | 1280kW |
| Rated permanent current at AC-23, 400 V | 160A |
| Voltage | 690V |
| Maximum Continuous Voltage | 690V |
| Degree of protection (IP) | IP00 |
| Amperage | 160A |
| Type of electric connection | Screw connection |
| Packed Quantity | 1 |
| Height | 141mm |
| Width | 314mm |
| Depth | 191mm |
| Colour | Black |
