GE1250 - 3P SWITCH DISCONNECTOR

Why Choose the GE1250?

Built for demanding switch disconnector duties, the Lovato GE1250 switch disconnector delivers dependable three‑pole AC isolation and switching at 1250 A Ith. With Ui 1000 V and Uimp 12 kV, the GE1250 suits plate‑mounted panels requiring IP20 frontal protection and robust performance. Conditional short‑circuit current is 72 kA with gG1250 fuse protection, supporting safe operation in industrial power distribution where reliable on‑load disconnection and isolation are essential.

Performance spans AC21A 1250 A at 400/500 V, AC22A up to 1250 A at 400 V, and AC23A up to 1000 A at 400 V. Rated operational power reaches 443 kW at 400 V AC23A and 478 kW at 690 V. A 10,000‑cycle mechanical life, −25 to 55 °C operation, 45 Nm terminal torque (max), 3000 m altitude and Pollution Degree 3 underline durability. Conforms to IEC/EN 60947‑1 and 60947‑3, with Sustainability certification.

Key Benefits

• High 1250 A Ith for heavy-duty AC isolation and switching.
• Three-pole configuration simplifies three-phase circuit isolation.
• Ui 1000 V and Uimp 12 kV enhance dielectric strength.
• AC21A/AC22A/AC23A ratings for versatile load switching at 400–690 V.
• IP20 frontal protection when panel-mounted improves operator safety.
• Mechanical life of 10,000 cycles ensures long service reliability.
• Conditional short-circuit current 72 kA with gG1250 fuse coordination.
• Operates from −25 to 55 °C for challenging environments.

Technical Specification

• Product type designation: GE
• Number of poles: 3
• Operating voltage type: AC
• Ith (IEC): 1250 A
• Rated insulation voltage Ui (IEC/EN): 1000 V
• Rated impulse withstand voltage Uimp: 12 kV
• Operating current Ie AC21A 400 V: 1250 A
• Operating current Ie AC21A 500 V: 1250 A
• Operating current Ie AC21A 690 V: 1000 A
• Operating current Ie AC22A 400 V: 1250 A
• Operating current Ie AC22A 500 V: 1000 A
• Operating current Ie AC22A 690 V: 630 A
• Operating current Ie AC23A 400 V: 1000 A
• Operating current Ie AC23A 500 V: 800 A
• Operating current Ie AC23A 690 V: 500 A
• Power dissipation per pole (max): 78 W
• Rated operational power AC23A 400 V: 443 kW
• Rated operational power AC23A 690 V: 478 kW
• Conditional short-circuit current (rms): 72 kA
• Short-circuit protection fuse: gG1250
• Making capacity AC23A 400 V: 8000 A
• Breaking capacity AC23A 400 V: 6400 A
• Mechanical life: 10000 cycles
• Terminal tightening torque (max): 45 Nm
• Operating temperature: -25 to 55 °C
• Storage temperature: -40 to 70 °C
• Max altitude: 3000 m
• IP degree (frontal): IP20
• Pollution degree: 3

What’s Included

• Lovato GE1250 switch disconnector
• Manufacturer documentation and safety information
• Product data sheet (downloadable)
• Protective packaging

Applications

• Main isolation for three‑phase AC distribution and control panels
• Load switching under AC21A, AC22A and AC23A duty categories
• Panel‑mounted disconnecting means with IP20 frontal protection
• High‑current incomer or feeder isolation up to 1250 A Ith

Safety note: Install and commission only by qualified personnel. De‑energise and verify isolation before work, use gG1250 fuses for short‑circuit protection, and follow IEC/EN 60947 and manufacturer instructions.
