GE1000 - 3P SWITCH DISCONNECTOR

Why Choose the GE1000?

Lovato’s GE1000 three-pole switch disconnector provides dependable AC isolation for industrial panels and equipment. Identified as SKU GE1000, it offers 1000 A Ith in free air, 1000 V rated insulation (Ui), and 12 kV impulse withstand (Uimp) for robust performance. Its screw-on-plate installation and IP20 frontal protection simplify safe, tidy panel integration, making it a strong choice for main isolation and load switching duties in power distribution.

High load switching is supported with AC-23A operational currents of 1000 A at 400 V, 800 A at 500 V, and 500 A at 690 V, plus a 72 kA conditional short-circuit rating with gG1000 fuse protection. Designed for durability with 10,000 mechanical cycles, it operates from -25 to 55 °C up to 3000 m altitude, meeting IEC/EN 60947-1 and 60947-3 requirements for low-voltage switchgear and controlgear.

Key Benefits

• 1000 A Ith handles heavy-duty isolation and load switching.
• Ui 1000 V and Uimp 12 kV ensure high insulation strength.
• AC-23A ratings up to 1000 A at 400 V for tough loads.
• 72 kA conditional short-circuit withstand with gG1000 fuse protection.
• IP20 frontal protection enhances safety during panel operation.
• Screw-on-plate mounting speeds clean, secure panel installation.
• 10,000 mechanical cycles for long, dependable service life.
• Operates -25 to 55 °C; usable up to 3000 m altitude.

Technical Specification

• Product type designation: GE
• Number of poles: 3
• Operating voltage type: AC
• Ith (IEC): 1000 A
• Rated insulation voltage Ui (IEC/EN): 1000 V
• Rated impulse withstand voltage Uimp: 12 kV
• Operating current Ie AC21A 400 V: 1000 A
• Operating current Ie AC21A 500 V: 1000 A
• Operating current Ie AC21A 690 V: 1000 A
• Operating current Ie AC22A 400 V: 1000 A
• Operating current Ie AC22A 500 V: 1000 A
• Operating current Ie AC22A 690 V: 630 A
• Operating current Ie AC23A 400 V: 1000 A
• Operating current Ie AC23A 500 V: 800 A
• Operating current Ie AC23A 690 V: 500 A
• Power dissipation per pole (max): 50 W
• Rated operational power AC23A 400 V: 443 kW
• Rated operational power AC23A 690 V: 478 kW
• Conditional short-circuit current (rms): 72 kA
• Short-circuit protection fuse: gG1000
• Making capacity AC23A 400 V: 8000 A
• Breaking capacity AC23A 400 V: 6400 A
• Mechanical life: 10000 cycles
• Terminal tightening torque (max): 45 Nm
• Operating temperature: -25 to 55 °C
• Storage temperature: -40 to 70 °C
• Max altitude: 3000 m
• IP degree (frontal): IP20
• Pollution degree: 3

What’s Included

• Lovato GE1000 three-pole switch disconnector
• Installation and safety instructions
• Manufacturer datasheet

Applications

• Main isolation in industrial power distribution panels
• Load breaking for AC circuits up to 690 V
• Machinery and plant maintenance isolation points
• Panel-mounted disconnecting means with IP20 frontal protection

Safety note: Install and commission only by qualified personnel. Isolate all supplies before work, use gG1000 fuses as specified, and observe tightening torques and IEC/EN 60947 guidelines.
