GE0800N - 3P SWITCH DISCONNECTOR W/NH FUSE HOLDER

Why Choose the GE0800N?

Designed for demanding AC installations, the Lovato GE0800N is a three‑pole switch disconnector with NH fuse holder rated at 800 A. With a robust GE product lineage and screw-on plate mounting, it delivers reliable isolation and protection. Rated insulation voltage Ui 1000 V and impulse withstand Uimp 12 kV provide confidence in harsh environments, while an IP20 frontal degree and pollution degree 3 support safer panel integration.

Engineered performance includes Ie up to 800 A in AC21A/AC22A at 400–500 V, and 630 A at 690 V; AC23A is 630 A at 400–500 V and 400 A at 690 V. Rated operational power reaches 355 kW at 400 V and 370 kW at 690 V. With 100 kA conditional short‑circuit rating, 5000 mechanical cycles, and operation from −25 to 55 °C up to 3000 m, it’s built for reliability.

Key Benefits

• 3-pole NH fuse switch disconnector rated at 800 A for AC.
• High insulation: Ui 1000 V and Uimp 12 kV resilience.
• Strong short-circuit capability with 100 kA conditional rating.
• AC23A power up to 370 kW at 690 V.
• Wide operating temperature −25 to 55 °C for varied environments.
• IP20 frontal protection and pollution degree 3 for safer panels.
• Screw-on plate mounting with 13 Nm max terminal tightening torque.

Technical Specification

• Product type designation: GE
• Number of poles: 3
• Operating voltage type: AC
• Ith (IEC): 800 A
• Rated insulation voltage Ui (IEC/EN): 1000 V
• Rated impulse withstand voltage Uimp: 12 kV
• Operating current Ie AC21A 400 V: 800 A
• Operating current Ie AC21A 500 V: 800 A
• Operating current Ie AC21A 690 V: 630 A
• Operating current Ie AC22A 400 V: 800 A
• Operating current Ie AC22A 500 V: 800 A
• Operating current Ie AC22A 690 V: 630 A
• Operating current Ie AC23A 400 V: 630 A
• Operating current Ie AC23A 500 V: 630 A
• Operating current Ie AC23A 690 V: 400 A
• Power dissipation per pole (max): 63 W
• Rated operational power AC23A 400 V: 355 kW
• Rated operational power AC23A 690 V: 370 kW
• Conditional short-circuit current (rms): 100 kA
• Making capacity AC23A 400 V: 6300 A
• Breaking capacity AC23A 400 V: 5100 A
• Mechanical life: 5000 cycles
• Terminal tightening torque (max): 13 Nm
• Operating temperature: -25 to 55 °C
• Storage temperature: -40 to 70 °C
• Max altitude: 3000 m
• IP degree (frontal): IP20
• Pollution degree: 3

What’s Included

• Lovato GE0800N switch disconnector with NH fuse holder
• Manufacturer datasheet (downloadable)

Applications

• AC isolation and switching in industrial distribution panels
• Fuse‑protected circuits using NH fuse technology
• Load breaking to AC23A duty for mixed resistive/inductive loads
• Main switch duties up to 800 A within switchboards
• Installations up to 3000 m altitude and pollution degree 3

Safety note: Installation and maintenance must be performed by qualified personnel. Always isolate power, use appropriate NH fuses, and tighten terminals to the specified torque. Observe IP20 frontal limits and operating conditions.
