GE0400B - 3P SWITCH DISCONNECTOR W/BS FUSE HOLDER

Why Choose the GE0400B?

Lovato GE0400B is a three-pole switch disconnector with BS fuse holder for AC applications, providing 400 A Ith and reliable isolation. Rated insulation voltage is 1000 V with 12 kV impulse withstand, and it suits screw-on-plate mounting. With AC21A, AC22A and AC23A duties supported up to 400 A, it delivers consistent performance in control panels and distribution assemblies.

Designed for demanding environments, GE0400B features 100 kA conditional short-circuit current, 4000 A making and 3200 A breaking capacity at AC23A 400 V, plus mechanical life of 10,000 cycles. Rated operational power is 220 kW at 400 V and 250 kW at 690 V (AC23A). IP20 frontal protection, operating temperature from -25 to 55 °C, altitude up to 3000 m, and compliance with IEC/EN 60947-1 and 60947-3 support safe, standards-aligned installations.

Key Benefits

• Three-pole AC switch disconnector with integrated BS fuse holder.
• 400 A Ith with AC21A/AC22A/AC23A duty support.
• Ui 1000 V and 12 kV impulse withstand for insulation robustness.
• Conditional short-circuit current 100 kA enhances fault tolerance.
• Rated operational power 220 kW at 400 V AC23A.
• IP20 frontal degree providing finger-safe front protection.
• Screw on plate installation; 24 Nm max terminal torque.

Technical Specification

• Product type designation: GE
• Number of poles: 3
• Operating voltage type: AC
• Ith (IEC): 400 A
• Rated insulation voltage Ui (IEC/EN): 1000 V
• Rated impulse withstand voltage Uimp: 12 kV
• Operating current Ie AC21A 400 V: 400 A
• Operating current Ie AC21A 500 V: 400 A
• Operating current Ie AC21A 690 V: 400 A
• Operating current Ie AC22A 400 V: 400 A
• Operating current Ie AC22A 500 V: 400 A
• Operating current Ie AC22A 690 V: 400 A
• Operating current Ie AC23A 400 V: 400 A
• Operating current Ie AC23A 500 V: 400 A
• Operating current Ie AC23A 690 V: 315 A
• Power dissipation per pole (max): 29 W
• Rated operational power AC23A 400 V: 220 kW
• Rated operational power AC23A 690 V: 250 kW
• Conditional short-circuit current (rms): 100 kA
• Making capacity AC23A 400 V: 4000 A
• Breaking capacity AC23A 400 V: 3200 A
• Mechanical life: 10000 cycles
• Terminal tightening torque (max): 24 Nm
• Operating temperature: -25 to 55 °C
• Storage temperature: -40 to 70 °C
• Max altitude: 3000 m
• IP degree (frontal): IP20
• Pollution degree: 3

What’s Included

• Lovato GE0400B switch disconnector with BS fuse holder (3-pole)
• Product datasheet and documentation

Applications

• AC distribution boards and switchgear panels
• Control panels and motor control centres
• Machinery isolation and maintenance switching
• Industrial and commercial power circuits requiring fused disconnection

Safety note: Installation and maintenance must be performed by qualified personnel. Isolate power before work, observe the specified ratings and environmental limits, use suitable BS fuses, and tighten terminals to the stated torque.
