GE0315B - 3P SWITCH DISCONNECTOR W/BS FUSE HOLDER

Why Choose the GE0315B?

The Lovato GE0315B is a three‑pole switch disconnector with BS fuse holder designed for reliable isolation and load switching in AC systems. Rated Ith 315 A and suitable for plate mounting, the GE0315B delivers robust performance across industrial panels. With Ui 1000 V and Uimp 12 kV, it provides strong dielectric capability while maintaining IP20 frontal protection and compliance with IEC/EN 60947‑1 and 60947‑3.

Engineered for demanding duties, it carries AC21A and AC22A currents of 315 A up to 690 V, and AC23A ratings of 315 A at 400/500 V (250 A at 690 V). High endurance is assured with 10,000 mechanical cycles, 100 kA conditional short‑circuit withstand, and 3150 A making/2600 A breaking (AC23A 400 V). Suitable for environments from −25 to +55 °C and altitudes to 3000 m, with plate‑mount screw installation.

Key Benefits

• AC21A/AC22A: 315 A at 400/500/690 V for versatile duty.
• AC23A: 315 A at 400/500 V; 250 A at 690 V.
• High dielectric strength: Ui 1000 V and Uimp 12 kV.
• Strong fault capability with 100 kA conditional short-circuit withstand.
• IP20 frontal protection enhances operator safety inside panels.
• Durable design rated for 10,000 mechanical operating cycles.
• Wide environmental range: −25 to +55 °C, altitude up to 3000 m.
• Secure plate mounting; terminals tighten up to 24 Nm.

Technical Specification

• Product type designation: GE
• Number of poles: 3
• Operating voltage type: AC
• Ith (IEC): 315 A
• Rated insulation voltage Ui (IEC/EN): 1000 V
• Rated impulse withstand voltage Uimp: 12 kV
• Operating current Ie AC21A 400 V: 315 A
• Operating current Ie AC21A 500 V: 315 A
• Operating current Ie AC21A 690 V: 315 A
• Operating current Ie AC22A 400 V: 315 A
• Operating current Ie AC22A 500 V: 315 A
• Operating current Ie AC22A 690 V: 315 A
• Operating current Ie AC23A 400 V: 315 A
• Operating current Ie AC23A 500 V: 315 A
• Operating current Ie AC23A 690 V: 250 A
• Power dissipation per pole (max): 24 W
• Rated operational power AC23A 400 V: 185 kW
• Rated operational power AC23A 690 V: 200 kW
• Conditional short-circuit current (rms): 100 kA
• Making capacity AC23A 400 V: 3150 A
• Breaking capacity AC23A 400 V: 2600 A
• Mechanical life: 10000 cycles
• Terminal tightening torque (max): 24 Nm
• Operating temperature: -25 to 55 °C
• Storage temperature: -40 to 70 °C
• Max altitude: 3000 m
• IP degree (frontal): IP20
• Pollution degree: 3

What’s Included

• Lovato GE0315B three-pole switch disconnector with BS fuse holder
• Installation and safety instructions
• Manufacturer datasheet (available online)

Applications

• Main isolator for industrial control panels and distribution boards
• Load switching for mixed resistive and motor loads (AC-23A duty)
• Incoming and outgoing circuit isolation up to 690 V AC
• Projects requiring IP20 frontal protection and BS fuse integration
• Plate-mounted installations in machinery and plant rooms

Safety note: Install and commission only by qualified personnel. Always isolate the supply before work, apply correct tightening torque, select appropriate BS fuses for the circuit, and operate within the stated ratings and environmental limits.
