GE0251 - 3P SWITCH DISCONNECTOR

Why Choose the GE0251?

Engineered for reliable isolation and switching, the Lovato GE0251 three-pole switch disconnector delivers 250 A AC performance for demanding industrial panels. With SKU GE0251, this unit mounts via screw-on plate, provides IP20 frontal protection, and is designed to IEC/EN 60947-1 and 60947-3. A 1000 V rated insulation voltage and 8 kV impulse withstand ensure robust dielectric strength across varied installations.

High utilisation categories are supported, with Ie up to 250 A in AC21A and AC22A at 400-500 V, and up to 250/200/160 A across AC23A duty at 400/500/690 V. Rated operational power reaches 138 kW at 400 V and 153 kW at 690 V. Low 2.5 W per-pole dissipation, 20,000 mechanical cycles, and operation from -25 to 55 °C enhance uptime.

Key Benefits

• Three-pole AC isolator with 250 A Ith for dependable switching.
• Ui 1000 V and Uimp 8 kV for strong dielectric resilience.
• Conditional short-circuit current 100 kA with gG250 fuse protection.
• AC21A, AC22A and AC23A performance across 400, 500 and 690 V.
• Low 2.5 W power dissipation per pole reduces panel heating.
• IP20 frontal protection supports safer operation and maintenance.
• Mechanical life of 20,000 cycles for long service.

Technical Specification

• Product type designation: GE
• Number of poles: 3
• Operating voltage type: AC
• Ith (IEC): 250 A
• Rated insulation voltage Ui (IEC/EN): 1000 V
• Rated impulse withstand voltage Uimp: 8 kV
• Operating current Ie AC21A 400 V: 250 A
• Operating current Ie AC21A 500 V: 250 A
• Operating current Ie AC21A 690 V: 200 A
• Operating current Ie AC22A 400 V: 250 A
• Operating current Ie AC22A 500 V: 250 A
• Operating current Ie AC22A 690 V: 160 A
• Operating current Ie AC23A 400 V: 250 A
• Operating current Ie AC23A 500 V: 200 A
• Operating current Ie AC23A 690 V: 160 A
• Power dissipation per pole (max): 2.5 W
• Rated operational power AC23A 400 V: 138 kW
• Rated operational power AC23A 690 V: 153 kW
• Conditional short-circuit current (rms): 100 kA
• Short-circuit protection fuse: gG250
• Making capacity AC23A 400 V: 2500 A
• Breaking capacity AC23A 400 V: 2000 A
• Mechanical life: 20000 cycles
• Terminal tightening torque (max): 18 Nm
• Operating temperature: -25 to 55 °C
• Storage temperature: -40 to 70 °C
• Max altitude: 3000 m
• IP degree (frontal): IP20
• Pollution degree: 3

What’s Included

• Lovato GE0251 three-pole switch disconnector (250 A)
• Manufacturer installation and safety information
• Protective packaging for transit

Applications

• Main or local isolation in industrial control panels
• Motor load switching to AC23A ratings at 400-690 V
• Power distribution boards requiring 250 A disconnection
• Maintenance lock-off and safety isolation duties
• Machinery or equipment incomer isolation in AC systems

Safety note: Install and commission only by a qualified electrician. Isolate all supplies before work, tighten terminals to the specified torque (max 18 Nm), and use the specified gG250 fuse to meet the conditional short-circuit rating.
