GE0250BT4 - 4P SWITCH DISCONNECTOR W/BS FUSE HOLDER

Why Choose the GE0250BT4?

Lovato’s GE0250BT4 is a four-pole switch disconnector with BS fuse holder for secure isolation and protection in AC applications. Delivering 250 A Ith with Ui 1000 V (IEC/EN) and Uimp 12 kV, it offers robust performance in panel assemblies. The screw-on plate mounting and IP20 frontal degree support straightforward integration while maintaining operator safety and clear segregation.

Designed for heavy-duty switching, it carries Ie 250 A for AC21A and AC22A up to 690 V, and 200 A at AC23A 690 V. With 100 kA conditional short-circuit rating, 2500 A making and 2000 A breaking (AC23A 400 V), and 10,000 mechanical cycles, it delivers assured durability. Operates -25 to 55 °C, IP20 front, Pollution Degree 3, plate-mount, and conforms to IEC/EN 60947-1/-3.

Key Benefits

• Four-pole BS-fused isolation for AC circuits up to 690 V.
• 250 A ratings for AC21A and AC22A duty across voltages.
• 200 A AC23A at 690 V for mixed-load switching.
• High short-circuit withstand: 100 kA conditional rating.
• IP20 frontal protection enhances operator safety at the panel.
• Durable mechanism, tested to 10,000 mechanical cycles.
• Plate-mounted design simplifies secure installation on switchboards.

Technical Specification

• Product type designation: GE
• Number of poles: 4
• Operating voltage type: AC
• Ith (IEC): 250 A
• Rated insulation voltage Ui (IEC/EN): 1000 V
• Rated impulse withstand voltage Uimp: 12 kV
• Operating current Ie AC21A 400 V: 250 A
• Operating current Ie AC21A 500 V: 250 A
• Operating current Ie AC21A 690 V: 250 A
• Operating current Ie AC22A 400 V: 250 A
• Operating current Ie AC22A 500 V: 250 A
• Operating current Ie AC22A 690 V: 250 A
• Operating current Ie AC23A 400 V: 250 A
• Operating current Ie AC23A 500 V: 250 A
• Operating current Ie AC23A 690 V: 200 A
• Power dissipation per pole (max): 12 W
• Rated operational power AC23A 400 V: 132 kW
• Rated operational power AC23A 690 V: 160 kW
• Conditional short-circuit current (rms): 100 kA
• Making capacity AC23A 400 V: 2500 A
• Breaking capacity AC23A 400 V: 2000 A
• Mechanical life: 10000 cycles
• Terminal tightening torque (max): 24 Nm
• Operating temperature: -25 to 55 °C
• Storage temperature: -40 to 70 °C
• Max altitude: 3000 m
• IP degree (frontal): IP20
• Pollution degree: 3

What’s Included

• GE0250BT4 switch disconnector with BS fuse holder assembly
• Installation and safety instructions
• Manufacturer datasheet (downloadable)

Applications

• Main isolation in AC panels up to 690 V
• Switching mixed resistive/inductive loads (AC23A duty)
• Fused protection in distribution and control assemblies
• Machine and process equipment isolation
• Plate-mounted installations in switchboards

Safety note: Installation must be performed by qualified personnel. Always isolate the supply before work, use BS fuses within the specified ratings, and observe tightening torque limits (max 24 Nm) in accordance with IEC/EN 60947.
