GE0161NT4 - 4P SWITCH DISCONNECTOR W/NH FUSE HOLDER

Why Choose the GE0161NT4?

Lovato GE0161NT4 is a four‑pole switch disconnector with NH fuse holder designed for dependable AC isolation and protection. Rated Ith 160 A with Ui 800 V and Uimp 8 kV, it supports AC21A/AC22A duty up to 690 V. Robust IP20 frontal protection and 100 kA conditional short‑circuit withstand make it ideal for industrial switchgear and panel applications.

Engineered for durability, the GE0161NT4 offers 10,000 mechanical cycles, secure terminals up to 13 Nm torque, and reliable operation from −25 to 55 °C at altitudes to 3000 m. Simple screw‑on plate installation and compliance with IEC/EN 60947‑1 and 60947‑3 streamline specification for OEMs and MROs seeking consistent AC23A performance, including 125 A at 690 V.

Key Benefits

• Four‑pole AC isolation with NH fuse protection up to 160 A Ith.
• Consistent Ie for AC21A/AC22A duties up to 690 V across phases.
• AC23A motor‑load switching capability, 125 A at 690 V.
• High conditional short‑circuit withstand, rated 100 kA rms.
• IP20 frontal protection with robust insulation to 800 V Ui.
• Wide operating temperature −25 to 55 °C; altitude capability to 3000 m.
• Durable mechanism rated for 10,000 mechanical cycles.
• Secure connections with terminals rated to 13 Nm tightening torque.

Technical Specification

• Product type designation: GE
• Number of poles: 4
• Operating voltage type: AC
• Ith (IEC): 160 A
• Rated insulation voltage Ui (IEC/EN): 800 V
• Rated impulse withstand voltage Uimp: 8 kV
• Operating current Ie AC21A 400 V: 160 A
• Operating current Ie AC21A 500 V: 160 A
• Operating current Ie AC21A 690 V: 160 A
• Operating current Ie AC22A 400 V: 160 A
• Operating current Ie AC22A 500 V: 160 A
• Operating current Ie AC22A 690 V: 160 A
• Operating current Ie AC23A 400 V: 160 A
• Operating current Ie AC23A 500 V: 160 A
• Operating current Ie AC23A 690 V: 125 A
• Power dissipation per pole (max): 13.5 W
• Rated operational power AC23A 400 V: 90 kW
• Rated operational power AC23A 690 V: 110 kW
• Conditional short-circuit current (rms): 100 kA
• Making capacity AC23A 400 V: 1600 A
• Breaking capacity AC23A 400 V: 1280 A
• Mechanical life: 10000 cycles
• Terminal tightening torque (max): 13 Nm
• Operating temperature: -25 to 55 °C
• Storage temperature: -40 to 70 °C
• Max altitude: 3000 m
• IP degree (frontal): IP20
• Pollution degree: 3

What’s Included

• Lovato GE0161NT4 four‑pole switch disconnector with NH fuse holder
• Manufacturer documentation (datasheet/user information)

Applications

• Industrial control panels requiring 4‑pole AC isolation up to 160 A
• Motor load switching duties (AC‑23A), including 125 A at 690 V
• Distribution and OEM switchboards with NH fuse protection
• On‑load disconnection and maintenance isolation in AC circuits

Safety note: Install and commission by qualified personnel only. De‑energise circuits before work, use appropriately rated NH fuses, and observe specified torque, temperature, and altitude limits per the datasheet.
