EZZ020642B Operator Attachment IP 20 with nuts

Why Choose the Yaskawa EZZ020642B Remote Operator Mounting Kit?

The Yaskawa EZZ020642B is a genuine remote operator mounting bracket kit designed for compatible Yaskawa LCD and LED digital operator keypads. Also known as Keypad Installation Set B, it allows a compatible drive operator to be mounted externally on an enclosure or control panel door for convenient access to drive monitoring, local operation and parameter settings.

This mounting kit is ideal for machine builders, panel builders and maintenance engineers who need access to the inverter keypad without opening the main electrical cabinet. It is commonly used with Yaskawa digital operators such as the JVOP-180 LCD operator and JVOP-182 LED operator, supporting neat and practical remote keypad installation.

The EZZ020642B is designed for external or face-mount installation where the enclosure already has suitable customer-supplied studs or fixing screws. The kit includes the bracket hardware required to secure the keypad to the bracket and attach the bracket to the enclosure, while the digital operator keypad and remote connection cable are normally supplied separately.

Key Advantages

• Genuine Yaskawa remote operator mounting bracket kit.
• Allows compatible LCD or LED keypad operators to be mounted externally.
• Suitable for JVOP-180 and JVOP-182 digital operators.
• Designed for enclosures using rear studs or customer-supplied fixing screws.
• Supports cleaner control panel design and easier operator access.
• Useful for drive monitoring, commissioning and parameter adjustment.

Key Features

• Yaskawa EZZ020642B keypad installation set.
• Remote operator mounting bracket kit for compatible digital keypads.
• Also described as LCD / LED Keypad Installation Set B.
• Designed for external or face-mount keypad installation.
• Supports compatible Yaskawa LCD and LED digital operators.
• Includes screws to mount the keypad to the bracket.
• Includes nuts for attaching the bracket to customer-supplied enclosure studs.
• Compact bracket design for straightforward panel installation.

Technical Specifications

• Manufacturer: Yaskawa
• Model: EZZ020642B
• Product type: Remote operator mounting bracket kit
• Alternative description: LCD / LED Keypad Installation Set B
• Application: Remote mounting of compatible Yaskawa digital operators
• Compatible digital operator: JVOP-180 LCD Digital Operator
• Compatible digital operator: JVOP-182 LED Digital Operator
• Compatible drive families: V1000, E1000, T1000A and selected compatible Yaskawa drive series where supported
• Mounting type: External / face-mount panel installation
• Protection style: IP20 mounting accessory
• Panel aperture required: approx. 59 × 89 mm
• Mounting dimensions: approx. 60 mm wide × 130 mm high × 13.9 mm deep
• Fixing hole layout: approx. 45 × 120 mm
• Supplied components: Mounting bracket, keypad fixing screws and enclosure fixing nuts
• Keypad included: No
• Connection cable included: No
• Typical installation location: Electrical enclosure door or control panel front

Convenient Remote Keypad Access for Drive Systems

Mounting accessories such as the Yaskawa EZZ020642B allow digital operator keypads to be positioned on the outside of a control panel or enclosure. This helps engineers view drive status, adjust parameters and perform local operation without opening the electrical cabinet during normal use.

When used with a compatible Yaskawa digital operator and remote operator cable, the EZZ020642B provides a practical remote keypad mounting solution for inverter drive systems. It is particularly useful in machinery panels, production equipment and automation systems where operator access and tidy panel layout are important.

Typical Applications

• Yaskawa drive keypad remote mounting.
• External digital operator access on electrical cabinets.
• Machine control panels and automation enclosures.
• Variable frequency drive monitoring and setup.
• OEM machine building and panel building projects.
• Maintenance-friendly drive installations.
