DCTLA4800360 - THYRISTOR MODULE 36 KVAR
MPN: DCTLA4800360
Special Price
£795.53
£662.94
Regular Price
£935.92
Why Choose the DCTLA4800360?
Optimise reactive power control with the Lovato DCTLA4800360 thyristor module. Delivering 36kvar at 480VAC and operating across 400...480VAC, this DCTL-designated module with current control enables fast, reliable switching in demanding power factor correction and industrial panels. It offers robust insulation at Ui 480 V and surge durability with Uimp 4 kV for dependable performance in UK installations.
Conformity with IEC/EN 60947-4-3, IEC/EN 61000-6-2 and IEC/EN 61000-6-4 supports dependable integration and EMC performance. With a rated insulation voltage Ui of 480 V and an impulse withstand Uimp of 4 kV, it is engineered for resilience. A 1740 g build and −30 to +80 °C storage range suit logistics, spares holding, and maintenance planning.
Key Benefits
- 36kvar at 480VAC for robust reactive power compensation stages.
- Rated operating voltage 400...480VAC for flexible deployment across low-voltage networks.
- Integrated current control for stable, precise thyristor switching.
- Ui 480 V insulation rating enhances electrical safety margins.
- Uimp 4 kV withstand capability for surge resilience.
- Compliant with IEC/EN 60947-4-3, 61000-6-2 and 61000-6-4.
- Wide storage temperature −30 to +80 °C aids logistics and spares.
- Sustainability certification provided by the manufacturer.
Technical Specification
- Product type designation: DCTL
- Rated insulation voltage Ui (IEC/EN): 480 V
- Rated impulse withstand voltage Uimp: 4 kV
- Storage temperature: -30 to +80 °C
- Weight: 1740 g
What’s Included
- Lovato DCTLA4800360 thyristor module
- Basic installation and safety information
- Manufacturer documentation reference
Applications
- Industrial power factor correction systems at 400–480 VAC
- Automatic capacitor banks for reactive power compensation
- Fast electronic switching in EMC-sensitive installations
- Upgrades and replacements in UK low-voltage distribution panels
Frequently Asked Questions
What reactive power is the module rated for?
It is rated at 36 kvar at 480 VAC.
What operating voltage range does it support?
The rated operating voltage is 400...480 VAC.
Does this thyristor module include current control?
Yes, it features current control for managed switching.
Which standards does the DCTLA4800360 conform to?
It conforms to IEC/EN 60947-4-3, IEC/EN 61000-6-2 and IEC/EN 61000-6-4.
What are the insulation and impulse withstand ratings?
Rated insulation voltage Ui is 480 V, and Uimp is 4 kV.
Safety note: Install and commission only by qualified personnel. Isolate all power sources before work, observe the stated ratings and standards, and store within −30 to +80 °C.
| Manufacturer Part Number | DCTLA4800360 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85371098 |
| Barcode | 8013975238004 |
