DCTLA4800180 - THYRISTOR MODULE 18 KVAR

Why Choose the DCTLA4800180?

Lovato DCTLA4800180 is a DCTL thyristor module delivering 18kvar at 480VAC with integrated current control. Designed for systems operating at 400...480VAC, it offers dependable operation in industrial control panels. An AC‑1 NO contact and 3A AC‑1 contact rating support straightforward control interfacing, while the 1740 g unit integrates cleanly into builds that prioritise consistent, specification‑led performance.

Built for reliability, the module features a rated insulation voltage Ui of 480 V and a 4 kV impulse withstand rating. It conforms to IEC/EN 60947-4-3 and EMC standards IEC/EN 61000-6-2 and 61000-6-4, with a storage temperature range of -30 to +80 °C. A Sustainability certification underlines responsible manufacture without compromising the published electrical specifications.

Key Benefits

• Delivers 18kvar performance at 480VAC with integrated current control.
• Rated operating voltage 400...480VAC suits common industrial supply ranges.
• AC‑1 NO contact and 3A AC‑1 rating ease control interfacing.
• Ui 480 V insulation rating for dependable dielectric separation.
• 4 kV impulse withstand capability against transient overvoltages.
• Conforms to IEC/EN 60947-4-3, 61000-6-2 and 61000-6-4.
• Wide storage temperature range from -30 to +80 °C.
• Sustainability certification supports responsible product selection.

Technical Specification

• Product type designation: DCTL
• Rated insulation voltage Ui (IEC/EN): 480 V
• Rated impulse withstand voltage Uimp: 4 kV
• Storage temperature: -30 to +80 °C
• Weight: 1740 g

What’s Included

• Lovato DCTLA4800180 thyristor module
• Manufacturer PDF datasheet (downloadable)
• Protective packaging for transit

Applications

• 400...480VAC electrical control systems requiring thyristor switching
• Installations needing current-controlled operation at 480VAC
• Control panels designed to IEC/EN 60947-4-3 compliance
• Sites with EMC requirements per IEC/EN 61000-6-2 and 61000-6-4

Safety note: Installation and maintenance must be performed by qualified personnel. Isolate all supplies before work, follow IEC/EN 60947-4-3 and applicable EMC practices, and observe the stated storage temperature range.
