Danfoss Variable Speed Drive 195N0001 VLT 2803 0.37KW/2.2Amps IP20 Standard Version
MPN: 195N0001
Alt. SKU: VLT2803PD2B20STR0DBF00A00C0
This product is discontinued. Please view this replacement item.
Why Choose the 195N0001?
The Danfoss 195N0001 (model code VLT2803PD2B20STR0DBF00A00C0) is a Variable speed drive (frequency converter) intended for panel installation where accurate motor control, repeatable commissioning, and reliable like-for-like replacement are required.
Configured with Power: 0.37kW / 0.5 HP, Current: 2.2 A, Supply: 200-240V AC, Enclosure: IP20, EMC/RFI: Without filter (No EMC) to support correct selection and like-for-like replacements.
Key Benefits
- Variable speed drive (frequency converter) for correct application matching
- Configured with Power: 0.37kW / 0.5 HP, Current: 2.2 A, Supply: 200-240V AC, Enclosure: IP20, EMC/RFI: Without filter (No EMC).
- Suitable for panel installations where reliable commissioning is required.
- SKU and model code shown for procurement and like for like replacements.
Technical Specifications
- Power Rating: 0.37kW / 0.5 HP
- Mains Voltage U(in): 200-240V AC
- Enclosure Class: IP20
- RFI Filter: Without filter (No EMC)
- Fieldbus Option: Without fieldbus option
- Display: Built In Display (SLCP)
- Height [mm]: 200
- Width w/ no C options [mm]: 75
- Depth [mm]: 168
- Net weight: 1.8 Kilogram
- EAN: 5702427033047
- Application Option: No application option
- Coating: Without coating
- Dedicated Application: Process
- Enclosure Type: Bookstyle
- Frame Size: A-Frame
- Gross weight: 2.029 Kilogram
- Hardware Configuration: Standard
- Modelcode01: VLT2803PD2B20STR0DBF00A00C0
- Product Group: VLT®
- Typecode Part 1: VLT2803PD2B20STR0DBF00A00C0
- VLT Series: 2800
Frequently Asked Questions
What supply does Danfoss 195N0001 require?
It is specified for 200-240V AC. Match this to your incoming mains.
What is the rated power for 195N0001?
The listed power rating is 0.37kW / 0.5 HP. Confirm sizing against your motor and duty cycle.
What enclosure class is it?
It is listed as IP20 and is intended for installation in a suitable cabinet/enclosure as required.
Does it include an EMC/RFI filter?
The configuration is shown as Without filter (No EMC). Choose a filtered variant or external filtering if your site requires it.
Where is 195N0001 typically installed?
In control panels or cabinets. Follow Danfoss installation guidance for clearances, earthing, and protective devices.
What does IP20 mean for 195N0001?
IP20 indicates protection against finger contact and solid objects over 12.5 mm. Install in a suitable enclosure to meet your site requirements.
| Manufacturer Part Number | 195N0001 |
|---|---|
| Filter | No Filter |
| Degree of protection (IP) | IP20 |
| KW Rating | 0.37kW, 0.55kW, 0.75kW |
| VSD Range | Danfoss VLT 2800 |
| Manufacturer | Danfoss |
| Alternative Product SKU | VLT2803PD2B20STR0DBF00A00C0 |
Write Your Own Review
The VLT Midi Drive fc 280 is an evolution of the VLT 2800 drive and benefits from a wide range of features designed to make installing, using and maintaining the AC drive as simple and easy as possible.
The VLT midi drive FC 280 is ideal for use within the automation and machine-build applications used in the food and beverage sector or materials handling and processing sector and provides fast, efficient service.
The drive offers a mid-power range and is strong on controls and safety while providing flexible fieldbus communications. It has a compact design and various functions are integrated, making it a space-saving unit that will slot into the tightest spaces.
The unit is compatible with the VLT 2800. Its exterior dimensions, connectors, cable lengths and set-up software tools mean it can easily be retrofitted in any established drive panel.
Supply voltages and power range
- 1 x 200-240 V...0.37-2.2 kW
- 3 x 200-240 V...0.37-3.7 kW
- 3 x 380-480 V...0.37-22 kW
Features and benefits
- Compact design saves panel space
- Easy and fast installation set-up due to flexible user interfaces
- No need to install extra cooling equipment or oversize the drive as it is designed to operate at 45°C at full load and up to 55°C with derating
- No need to install extra components thanks to integrated harmonic mitigation, RFI filters, brake choppers and functional safety (STO)
- Integrated active Power Factor Correction (PFC) significantly reduces harmonic distortion and improves power supply quality
For further information on this product please get in touch with our team or visit the Danfoss website.
