CV-4050-H3 KMF3100A Teco 37.5KW/80Amps IP00 Inverter Commercial Filter 3Phase Input 3Phase Output
MPN: CV-4050-H3 KMF3100A
Alt. SKU: CV4050H3KMF3100A
Why Choose the TECO CV-4050-H3 KMF3100A Industrial AC Drive?
The TECO CV-4050-H3 KMF3100A is a robust industrial variable frequency drive engineered for precise and efficient control of three phase induction motors in demanding industrial and process environments. Part of TECO’s CV drive family, this model combines rugged hardware, flexible motor control and built-in protection features to support a wide range of applications including pumps, fans, conveyors and other rotating machinery where dependable performance and seamless integration are needed.
Designed for continuous industrial duty, the CV-4050-H3 KMF3100A delivers smooth adjustable speed performance, integrated communications support, comprehensive motor and drive protection and flexible I/O options. Its combination of durability and capability makes it suitable for OEM systems, factory automation and heavy process installations.
Key Features
- Rated performance: Suitable for mid to heavy duty three phase motors typical of the 50 HP (≈ 37 kW) class.
- Control modes: Volts per hertz (V/Hz) and sensorless vector control for stable and efficient speed regulation.
- Wide frequency range: Programmable output frequency up to 400 Hz for versatile motor tuning.
- Built in communications: Standard Modbus RTU and support for optional fieldbus modules (Profibus, DeviceNet, EtherNet/IP etc) for PLC and automation integration.
- Configurable I/O: Digital and analogue inputs and outputs for tailored control and interfacing with external logic or safety systems.
- Protection features: Overcurrent, overload, undervoltage, overvoltage and thermal protection to safeguard the drive and motor.
- Safety functions: Built-in support for Safe Torque Off (STO) and other machine safety options depending on configuration.
- Diagnostics and interface: LCD or keypad display for status feedback, parameter ordering and fault reporting.
- Industrial design: Rugged enclosure and cooling suited to panel or cabinet mounting in heavy-duty installations.
Technical Specifications
- Manufacturer: TECO
- Series: CV Industrial AC Drives
- Model: CV-4050-H3 KMF3100A
- Rated output power: Approx. 50 HP class (around 37 kW)
- Input voltage: Three phase 380–480 V AC industrial supply
- Control methods: V/Hz and sensorless vector
- Output frequency range: 0–400 Hz
- Communications: Modbus RTU built in, optional fieldbus modules supported
- Protection functions: Overcurrent, overload, under/overvoltage and thermal protection
- Safety features: STO support and optional safety extensions when configured
- Mounting: Panel or control cabinet
- Enclosure rating: Industrial class
Typical Applications
- Industrial pump stations and booster sets
- Ventilation and extraction fan drives
- Conveyors and material handling equipment
- Process machines and factory automation systems
- HVAC and chilled water installations
- OEM control panels and retrofit motor control projects
Frequently Asked Questions
What power range does the CV-4050-H3 KMF3100A cover?
This drive is typically specified for around the 50 HP class of three phase motor control, suitable for mid to heavy duty industrial loads.
Which control methods are available?
The CV series supports both V/Hz and sensorless vector control to deliver smooth and efficient speed regulation as load conditions change.
Can this drive be integrated with modern automation systems?
Yes. Built in Modbus RTU and optional fieldbus network modules allow straightforward integration with PLC, SCADA and other automation or building management systems.
Trusted by Engineers and Integrators
Selected for robust performance, flexible control and easy integration in demanding industrial, OEM and automation environments.
| Manufacturer Part Number | CV-4050-H3 KMF3100A |
|---|---|
| Filter | Separate filter included |
| Input Phases | Three Phase |
| Degree of protection (IP) | IP00 |
| KW Rating | 37.5kW |
| Output Phases | Three phase |
| Manufacturer | TECO |
| Alternative Product SKU | CV4050H3KMF3100A |
