CV-4030-H3 KMF370A Teco 22KW/48 Amps IP20 Inverter Commercial Filter 3Phase Input 3Phase Output
MPN: CV-4030-H3 KMF370A
Alt. SKU: CV4030H3KMF370A
Why Choose the TECO CV-4030-H3 KMF370A Industrial AC Drive?
The TECO CV-4030-H3 KMF370A is a reliable industrial variable frequency drive from TECO’s CV series, designed to deliver efficient and precise speed control for three phase induction motors in demanding pump, fan and process control applications. This drive combines rugged construction with advanced motor control capability, making it suitable for continuous industrial operation in factories, utilities and commercial systems.
With an approximate power rating of 30 HP (around 22 kW) on a 380 to 480 V three phase supply, the CV-4030-H3 KMF370A offers smooth adjustable speed performance, flexible I/O and built in communications support, along with comprehensive protection features to safeguard both drive and motor in industrial environments.
Key Features
- Rated performance: Approx. 30 HP (≈ 22 kW) class for three phase motor control in mid range industrial applications.
- Flexible control modes: Volts per hertz (V/Hz) and sensorless vector control for efficient and stable speed regulation across varied loads.
- Wide frequency range: Programmable output frequency up to 400 Hz for tailored motor tuning.
- Built in communications: Modbus RTU standard, with optional fieldbus modules (such as Profibus, DeviceNet or Ethernet) for PLC and automation integration.
- Configurable I/O: Digital and analogue inputs and outputs for tailored control and interfacing with external logic systems.
- Protection functions: Overcurrent, overload, undervoltage, overvoltage and thermal protection safeguard the drive and motor.
- Safety support: Integrated support for Safe Torque Off (STO) and optional safety extensions depending on configuration.
- Diagnostics and interface: LCD or keypad display for status feedback, parameter setup and fault indication.
- Industrial design: Rugged enclosure for panel or cabinet mount in heavy duty environments.
Technical Specifications
- Manufacturer: TECO
- Series: CV Industrial AC Drives
- Model: CV-4030-H3 KMF370A
- Rated output power: Approx. 30 HP (≈ 22 kW)
- Input voltage: Three phase 380–480 V AC industrial supply
- Control modes: V/Hz and sensorless vector
- Output frequency range: 0–400 Hz
- Communications: Modbus RTU built in, optional fieldbus supported
- Protection functions: Overcurrent, overload, under/overvoltage and thermal protection
- Safety functions: Safe Torque Off (STO) support when fitted
- Mounting: Panel or cabinet mount
- Enclosure rating: Industrial class
Typical Applications
- Industrial pump and booster systems
- Ventilation and extraction fan drives
- Centrifugal and recirculation pump installations
- Process machinery and automation systems
- HVAC and chilled water systems
- OEM control panels and retrofit motor speed control projects
Frequently Asked Questions
What power range does the CV-4030-H3 KMF370A cover?
This model is typically rated around 30 HP (about 22 kW) on a 380 to 480 V three phase supply, suitable for mid range industrial motor control duties.
Which control methods does it support?
The CV series supports both V/Hz and sensorless vector control for stable and efficient speed regulation across varied load profiles.
Can this drive integrate with automation systems?
Yes. Modbus RTU is built in, and optional fieldbus modules can be fitted for integration with PLC, SCADA and other automation platforms.
Trusted by Engineers and Integrators
Chosen for dependable mid power performance, flexible control and comprehensive protection in demanding industrial and automation environments.
| Manufacturer Part Number | CV-4030-H3 KMF370A |
|---|---|
| Filter | Separate filter included |
| Input Phases | Three Phase |
| Degree of protection (IP) | IP20 |
| KW Rating | 22kW |
| Output Phases | Three phase |
| Manufacturer | TECO |
| Alternative Product SKU | CV4030H3KMF370A |
