Vacon 100 at LED Controls: your Official Danfoss Drives Authorised Partner
The Danfoss Vacon 100 range is a versatile and robust series of AC drives designed for a wide range of industrial motor control applications. As a Danfoss Drives Authorised Partner, LED Controls distributes Vacon 100 drives rapidly and with expert support, ensuring you get the right product for your application.
What is a Vacon 100 Drive?
A Vacon 100 drive is a Variable Speed Drive which controls the speed and torque of an electric motor by adjusting the electrical frequency supplied to it. This allows motors to run as fast as needed at any given time, improving efficiency and reducing wear. The Vacon 100 range is an all-rounder, designed to offer easy installation, commissioning, and operation across both simple and complex systems across many industries.
Key Features of the Vacon 100 Range
- Power range from 0.55 kW to 800 kW
- Built-in communication protocols for system integration
- Flexible enclosure options including IP21 and IP54
- Long service life with durable components
- Advanced motor control without requiring additional sensors
- Energy monitoring and optimisation tools
Typical Applications
- Conveyors
- Extruders
- Thrusters
- Sawmills
- Compressors
- Mixers
These applications benefit from consistent torque, reliable control, and flexible integration .
Vacon 100 Range Available from LED Controls
| Part Number | Power (CT / VT) | Current (CT / VT) | IP Rating |
|---|---|---|---|
| VACON0100-3L-0003-5 | 0.75 / 1.1 kW | 2.6 / 3.4 A | IP21 |
| VACON0100-3L-0004-5 | 1.1 / 1.5 kW | 3.4 / 4.8 A | IP20 |
| VACON0100-3L-0005-5 | 1.5 / 2.2 kW | 4.8 / 5.6 A | IP21 |
| VACON0100-3L-0008-5 | 2.2 / 3.0 kW | 5.6 / 8.0 A | IP21 |
| VACON0100-3L-0009-5 | 3.0 / 4.0 kW | 8.0 / 9.6 A | IP21 |
| VACON0100-3L-0012-5 | 4.0 / 5.5 kW | 9.6 / 12.0 A | IP21 |
| VACON0100-3L-0016-5 | 5.5 / 7.5 kW | 12.0 / 16.0 A | IP21 |
| VACON0100-3L-0023-5 | 7.5 / 11 kW | 16.0 / 23 A | IP21 |
| VACON0100-3L-0031-5 | 11 / 15 kW | 23 / 31 A | IP21 |
| VACON0100-3L-0038-5 | 15 / 18.5 kW | 31 / 38 A | IP21 |
| VACON0100-3L-0046-5 | 18.5 / 22 kW | 38 / 46 A | IP21 |
| VACON0100-3L-0061-5 | 22 / 30 kW | 46 / 61 A | IP21 |
| VACON0100-3L-0072-5 | 30 / 37 kW | 61 / 72 A | IP20 |
| VACON0100-3L-0087-5 | 37 / 45 kW | 72 / 87 A | IP21 |
| VACON0100-3L-0105-5 | 45 / 55 kW | 87 / 105 A | IP21 |
| VACON0100-3L-0140-5 | 55 / 75 kW | 105 / 140 A | IP21 |
| VACON0100-3L-0170-5 | 75 / 90 kW | 140 / 170 A | IP20 |
| VACON0100-3L-0205-5 | 90 / 110 kW | 170 / 205 A | IP21 |
| VACON0100-3L-0261-5 | 110 / 132 kW | 205 / 261 A | IP20 |
| VACON0100-3L-0310-5 | 132 / 160 kW | 245 / 300 A | IP21 |
| VACON0100-3L-0003-5 | 0.75 / 1.1 kW | 2.6 / 3.4 A | IP54 |
| VACON0100-3L-0004-5 | 1.1 / 1.5 kW | 3.4 / 4.8 A | IP54 |
| VACON0100-3L-0005-5 | 1.5 / 2.2 kW | 4.8 / 5.6 A | IP54 |
| VACON0100-3L-0008-5 | 2.2 / 3.0 kW | 5.6 / 8.0 A | IP54 |
| VACON0100-3L-0009-5 | 3.0 / 4.0 kW | 8.0 / 9.6 A | IP54 |
| VACON0100-3L-0012-5 | 4.0 / 5.5 kW | 9.6 / 12.0 A | IP54 |
| VACON0100-3L-0016-5 | 5.5 / 7.5 kW | 12.0 / 16.0 A | IP54 |
| VACON0100-3L-0023-5 | 7.5 / 11 kW | 16.0 / 23 A | IP54 |
| VACON0100-3L-0031-5 | 11 / 15 kW | 23 / 31 A | IP54 |
| VACON0100-3L-0038-5 | 15 / 18.5 kW | 31 / 38 A | IP54 |
| VACON0100-3L-0046-5 | 18.5 / 22 kW | 38 / 46 A | IP54 |
| VACON0100-3L-0061-5 | 22 / 30 kW | 46 / 61 A | IP54 |
| VACON0100-3L-0072-5 | 30 / 37 kW | 61 / 72 A | IP54 |
| VACON0100-3L-0087-5 | 37 / 45 kW | 72 / 87 A | IP54 |
| VACON0100-3L-0105-5 | 45 / 55 kW | 87 / 105 A | IP54 |
| VACON0100-3L-0140-5 | 55 / 75 kW | 105 / 140 A | IP54 |
| VACON0100-3L-0170-5 | 75 / 90 kW | 140 / 170 A | IP54 |
| VACON0100-3L-0205-5 | 90 / 110 kW | 170 / 205 A | IP54 |
| VACON0100-3L-0261-5 | 110 / 132 kW | 205 / 261 A | IP54 |
| VACON0100-3L-0310-5 | 132 / 160 kW | 245 / 300 A | IP54 |
Why Buy Vacon 100 from LED Controls?
LED Controls is a Danfoss Drives Authorised Partner, meaning we are licenced to distribute authentic Vacon products with quick access to the complete range, and we can offer expert advice on selection and reliable support post-purchase support. We work closely with customer and supplier to ensure that the perfect Vacon 100 solution is provided every time.
The Danfoss Vacon 100 range delivers reliable, flexible motor control across a wide range of industrial applications. With its strong performance, ease of use, and long service life, it remains a leading choice for modern drive systems. Either order yours online today or get in touch to find out more!
