BF38T2L048 - 4P CONTACTOR 2NO+2NC 56A AC1 48VDC B.C.

Why Choose the BF38T2L048?

Lovato BF38T2L048 is a robust four‑pole contactor designed for dependable switching in industrial panels. Featuring a 48V DC low‑consumption coil and AC1 Ith of 56A, it delivers reliable performance for resistive and general loads. With AC3 400V ratings of 38A/18.5Kw and a UL/CSA 480V motor rating of 30 HP, this compact unit integrates easily into new builds and retrofits.

Engineered for flexibility, the contactor mounts via screws or on 35mm DIN rail, and meets IEC/EN/BS 60947 and UL/CSA standards. A 690 V rated insulation, 6 kV impulse withstand, and up to 20,000,000 mechanical cycles support long service life. It operates from −50 to 70 °C and up to 3000 m altitude, suiting harsh environments and modern control panels alike.

Key Benefits

• Low-consumption 48V DC coil reduces control power demand.
• Rated 56A AC1 for dependable switching of resistive loads.
• AC3 38A/18.5Kw at 400V for motor applications.
• Flexible screw or 35mm DIN rail mounting.
• Long mechanical life up to 20,000,000 cycles.
• Wide operating temperature −50 to 70 °C for harsh sites.
• High insulation 690 V and 6 kV impulse withstand.
• Compliant with IEC/EN/BS, UL and CSA standards.

Technical Specification

• Product type designation: BF38
• Number of poles: 4
• Rated insulation voltage Ui (IEC/EN): 690 V
• Rated impulse withstand voltage Uimp: 6 kV
• Ith (IEC): 56 A
• Terminal tightening torque: 2.5 to 3 Nm
• Weight: 665 g
• Mechanical life: 20000000 cycles
• Operating temperature: -50 to 70 °C
• Storage temperature: -60 to 80 °C
• Max altitude: 3000 m
• Pollution degree: 3

What’s Included

• Lovato BF38T2L048 four-pole contactor
• Manufacturer documentation (online)
• Protective packaging for transit

Applications

• Motor starters and control circuits (AC3 duty)
• Switching resistive and general loads (AC1)
• HVAC and building services panels
• Pumping, conveyors and process equipment
• Industrial automation and machinery control

Safety note: Install and service only by qualified personnel. Isolate all power before work, observe specified tightening torque, and follow applicable IEC/EN/BS and UL/CSA standards and local regulations.
