BF38T2A46060 - 4P CONTACTOR 2NO+2NC 56A 460V 60HZ
MPN: BF38T2A46060
Special Price
£243.79
£203.16
Regular Price
£406.32
Why Choose the BF38T2A46060?
The Lovato BF38T2A46060 four‑pole contactor (SKU: BF38T2A46060) delivers dependable switching for AC control and power circuits. Rated Ith 56 A (AC1) with AC3 38 A/18.5 kW at 400 V, it features a 460 VAC 60 Hz AC coil and a flexible 2NO/2NC contact arrangement. Screw or 35 mm DIN rail mounting simplifies panel integration while maintaining a compact, robust BF38 platform engineered for demanding industrial environments.
Designed to IEC/EN/BS 60947 and UL/CSA standards, this BF38 contactor offers Ui 690 V and Uimp 6 kV for reliable dielectric performance. A mechanical life of 20,000,000 cycles supports long service, with operation from −50 to 70 °C and installation up to 3000 m altitude. Terminal tightening torque is 2.5–3 Nm, with Pollution Degree 3 construction and a weight of 522 g for solid, durable assembly.
Key Benefits
- Four‑pole design with 2NO/2NC contacts for versatile power and control switching.
- 56 A AC1 rating ensures robust performance for resistive load applications.
- AC3 38 A/18.5 kW at 400 V for motor duty switching.
- 460 VAC 60 Hz coil compatible with common industrial control supplies.
- Screw or 35 mm DIN rail mounting for quick, secure installation.
- Rated Ui 690 V and Uimp 6 kV for strong insulation and surge withstand.
- Mechanical life up to 20,000,000 cycles for extended service reliability.
- UL/CSA horsepower rating 30 HP at 480 V.
Technical Specification
- Product type designation: BF38
- Number of poles: 4
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 56 A
- Terminal tightening torque: 2.5 to 3 Nm
- Weight: 522 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to 70 °C
- Storage temperature: -60 to 80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BF38T2A46060 four‑pole contactor (2NO/2NC)
- Integrated 460 VAC 60 Hz AC coil
- Manufacturer documentation (downloadable)
- Protective factory packaging
Applications
- Motor control switching at 400 V AC3 duty up to 38 A
- Resistive load switching up to 56 A AC1
- Industrial control panels and machinery power switching
- HVAC, pump and compressor starters in building services
Frequently Asked Questions
What coil voltage and frequency does the BF38T2A46060 use?
It has an AC coil rated 460 V at 60 Hz.
How many poles and what contact configuration are provided?
It is a four‑pole device with 2NO and 2NC contacts.
What are the AC1 and AC3 ratings?
AC1 Ith is 56 A; AC3 at 400 V is 38 A/18.5 kW.
How is this contactor mounted in a panel?
It supports screw mounting or 35 mm DIN rail mounting.
Which standards does the product conform to?
It conforms to IEC/EN/BS 60947-1/-4-1, UL 60947-1/-4-1 and CSA C22.2 equivalents.
Safety note: Installation and commissioning must be performed by qualified personnel. Isolate supplies before work, tighten terminals to 2.5–3 Nm, and operate within stated ratings and temperature limits. Follow IEC/EN/BS 60947 and local regulations.
| Manufacturer Part Number | BF38T2A46060 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975162392 |
| Coil Voltage | 460V |
