BF3800D024 Lovato contactor 3 pole AC3:38A 18.5kw 24VDC coil
MPN: BF3800D024
Special Price
£180.07
£150.06
Regular Price
£300.11
Why Choose the BF3800D024?
Designed for dependable motor switching, the Lovato BF3800D024 three‑pole contactor delivers 38A AC‑3 at 400V with a 24V DC coil. The BF3800D024 supports screw or 35mm DIN rail mounting for quick panel integration and meets IEC/EN/BS 60947 and UL/CSA standards. With Ui 690V and 6kV impulse withstand, it offers robust insulation performance for industrial environments.
Engineered for longevity and harsh conditions, this BF38 series contactor achieves 20,000,000 mechanical cycles and operates from −50 to 70 °C up to 3000 m altitude. It provides 56 A Ith (AC1), 30 HP at 480V, and secure terminations with 2.5–3 Nm torque. Pollution degree 3 construction ensures reliability across demanding applications, from pumps and compressors to HVAC fans and conveyors.
Key Benefits
- 38A AC‑3 at 400V supports motors up to 18.5 kW.
- 24V DC coil allows precise, efficient control switching.
- Wide −50 to 70 °C operating temperature for harsh environments.
- Mechanical life of 20,000,000 cycles minimises maintenance.
- Ui 690 V and Uimp 6 kV enhance insulation robustness.
- Screw or 35 mm DIN rail mounting simplifies installation.
- Certified to IEC/EN/BS and UL/CSA standards for compliance.
- 30 HP rating at 480V accommodates demanding motor loads.
Technical Specification
- Product type designation: BF38
- Number of poles: 3
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 56 A
- Terminal tightening torque: 2.5 to 3 Nm
- Weight: 554 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to 70 °C
- Storage temperature: -60 to 80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BF3800D024 three‑pole contactor
- Manufacturer datasheet (PDF)
- Installation and safety instructions
- Protective packaging for transit
Applications
- Motor starters for pumps, fans and conveyors
- HVAC fan and blower control
- Pumps and compressors
- Conveyors and material handling systems
- General industrial automation and process equipment
Frequently Asked Questions
What is the coil voltage and type for the BF3800D024?
It uses a DC coil rated at 24 V.
What is its AC‑3 current rating at 400 V?
It is rated 38 A AC‑3 at 400 V, supporting up to 18.5 Kw.
How can it be mounted in a panel?
It supports screw mounting or 35 mm DIN rail installation.
What operating temperatures can it withstand?
The specified operating temperature range is −50 to 70 °C.
Which standards does it comply with?
It conforms to IEC/EN/BS 60947-1 and 60947-4-1, plus UL and CSA equivalents.
Safety note: Install and service only by qualified personnel. Isolate all power before work, follow IEC/EN/BS 60947 guidelines, and tighten terminals to 2.5–3 Nm. Observe pollution degree 3 and altitude limits.
| Manufacturer Part Number | BF3800D024 |
|---|---|
| HS Code | 85365080 |
| Manufacturer | Lovato |
| KW Rating | 18.5kW |
| Number of Poles | 3 Pole |
| Coil Voltage | 24VDC |
| AC3 Amperage | 38A |
| AC1 Amperage | 60A |
| Barcode | 8013975166680 |
