BF265T4E230 LOVATO MAXI 4P CONTACTOR 450A AC1 100-250VAC/DC

Why Choose the Lovato BF265T4E230 BF Series Four-Pole Contactor?

The Lovato BF265T4E230 is a high-performance four-pole power contactor designed for reliable switching of high-current electrical loads in industrial control systems. As part of the Lovato BF series, it is built for demanding automation, machinery and panel-building applications where dependable contactor operation is essential.

This contactor provides a robust solution for heavy-duty switching circuits, offering a rated thermal current of 450 A in AC-1 duty and an AC-3 operating current of 265 A. Its four-pole configuration makes it suitable for applications requiring switching of multiple poles, including resistive loads, distribution circuits and selected motor control installations.

With a 100-250 V AC/DC electronic coil, 1000 V rated insulation voltage and screw terminal connection, the BF265T4E230 is ideal for industrial switchgear, control panels, automation systems and high-current load switching. Its wide-range AC/DC coil helps simplify installation and supports flexible control circuit design.

Key Advantages

• Heavy-duty four-pole contactor for industrial power switching.
• 450 A AC-1 thermal current rating for high-current load applications.
• 265 A AC-3 operating current suitable for demanding motor control duties.
• 132 kW motor power rating at 400 V AC in AC-3 duty.
• Wide-range 100-250 V AC/DC electronic coil.
• 1000 V rated insulation voltage for industrial electrical systems.
• Screw terminal connection for secure high-current wiring.

Key Features

• Lovato BF series power contactor.
• Four-pole contactor configuration.
• 450 A rated thermal current in AC-1 duty.
• 265 A rated operating current in AC-3 duty.
• 132 kW rated motor power at 400 V AC.
• AC/DC wide-range electronic coil.
• 100-250 V AC/DC control voltage.
• Designed for screw mounting and screw terminal connection.

Technical Specifications

• Manufacturer: Lovato Electric
• Series: BF
• Model: BF265T4E230
• Product type: Four-pole power contactor
• Number of poles: 4
• Product type designation: BF265
• Rated thermal current AC-1: 450 A
• Rated operating current AC-3: 265 A
• Rated motor power AC-3 at 400 V: 132 kW
• Rated operational power AC-1 at 400 V: 296 kW
• Rated insulation voltage: 1000 V
• Rated impulse withstand voltage: 8 kV
• Operational frequency: 25-400 Hz
• Coil type: AC/DC electronic coil
• Rated coil voltage: 100-250 V AC/DC
• UL/CSA horsepower rating at 480 V: 200 HP
• Photovoltaic application: Yes
• Mounting type: Screw mounting
• Connection type: Screw connection
• Power terminal protection: IP00
• Operating temperature: -40 to +70 °C
• Storage temperature: -50 to +80 °C
• Maximum altitude: 3000 m
• Mechanical life: 5,000,000 cycles
• Standards: IEC/EN/BS 60947-1, IEC/EN/BS 60947-4-1, UL 60947-1, UL 60947-4-1, CSA C22.2 n° 60947-1, CSA C22.2 n° 60947-4-1
• Package dimensions: approx. 276 × 235 × 245 mm
• Weight: approx. 6.135 kg
• EAN: 8013975312582
• HS code: 85365080

Reliable Switching for High-Current Control Systems

Contactors such as the Lovato BF265T4E230 are used to switch electrical power to high-current loads from a control circuit. In industrial switchgear and automation panels, they provide dependable switching for motors, resistive loads and multi-pole electrical circuits.

The BF265T4E230 is designed for demanding applications where high current capacity, four-pole switching and flexible control voltage compatibility are important. Its wide-range AC/DC coil and robust BF series construction make it suitable for machinery manufacturers, control panel builders and maintenance teams working with high-power electrical systems.

Typical Applications

• Industrial power switching panels.
• High-current resistive load control.
• Large motor starter assemblies.
• Pump, fan and compressor control systems.
• Manufacturing and process machinery.
• HVAC and building services control panels.
• Photovoltaic switching applications.
• OEM machinery and automation systems.

Trusted by Industrial Control Professionals

Lovato BF series contactors are used by panel builders, automation engineers and maintenance professionals to provide reliable switching and high-current control in demanding industrial applications.
