BF265T4E024 LOVATO MAXI 4P CONTACTOR 450A AC1 24-60VAC/20-60VDC
MPN: BF265T4E024
Special Price
£1,089.17
£907.64
Regular Price
£1,815.28
Why Choose the BF265T4E024?
Designed for high-current switching, the Lovato BF265T4E024 four‑pole contactor delivers reliable control in demanding installations. With an AC/DC coil rated 24…60VAC / 20…60VDC and AC1 Ith of 450 A, it suits heavy-duty power distribution. At 400 V AC3 it handles 265 A (132 kW), giving robust motor control performance. Screw mounting simplifies panel integration and supports secure, long-term operation.
Built to international standards, this BF265 series contactor provides Ui of 1000 V and Uimp of 8 kV, plus a mechanical life of 5,000,000 cycles. Operating from -40 to 70 °C and up to 3000 m altitude, it is ready for harsh environments. Conformity includes IEC/EN/BS 60947-1/-4-1, UL and CSA, ensuring assurance in UK industrial applications.
Key Benefits
- Wide-range AC/DC coil 24…60VAC / 20…60VDC for flexible control voltage.
- High AC1 Ith 450 A for heavy-duty power switching reliability.
- Strong AC3 400 V rating 265 A / 132 kW for motor loads.
- Rated Ui 1000 V and Uimp 8 kV for insulation robustness.
- Extended temperature range -40 to 70 °C for harsh environments.
- Long mechanical life of 5,000,000 cycles reduces maintenance downtime.
- Screw mounting simplifies secure panel installation.
- Standards compliance IEC/EN/BS, UL, CSA for global acceptance.
Technical Specification
- Product type designation: BF265
- Number of poles: 4
- Rated insulation voltage Ui (IEC/EN): 1000 V
- Rated impulse withstand voltage Uimp: 8 kV
- Ith (IEC): 450 A
- Terminal tightening torque: 35 to 35 Nm
- Mechanical life: 5000000 cycles
- Operating temperature: -40 to 70 °C
- Storage temperature: -50 to 80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BF265T4E024 four-pole contactor
- Manufacturer datasheet (downloadable)
- Basic user and safety information
- Protective packaging
Applications
- Heavy-duty motor starters at 400 V AC3 up to 265 A
- Power distribution and switching up to 450 A AC1 loads
- Industrial pumps, compressors and HVAC fan assemblies
- Control of resistive and slightly inductive loads
- Panel-building for process, utilities and manufacturing
Frequently Asked Questions
What coil voltage range does the BF265T4E024 support?
It has an AC/DC coil rated 24…60VAC and 20…60VDC.
Is it suitable for AC3 motor loads at 400 V?
Yes, it is rated 265A / 132 kW at 400 V AC3.
Which standards does this contactor conform to?
It conforms to IEC/EN/BS 60947-1 and 60947-4-1, UL 60947-1/-4-1, and CSA equivalents.
What is the operating temperature range?
The specified operating temperature is -40 to 70 °C.
How is it mounted and how many poles does it have?
It uses screw mounting and has four poles.
Safety note: Installation and commissioning must be performed by qualified personnel with power isolated. Adhere to the manufacturer documentation and applicable standards, and operate within the specified ratings and environmental limits.
| Manufacturer Part Number | BF265T4E024 |
|---|---|
| HS Code | 85365080 |
| Manufacturer | Lovato |
| KW Rating | 132kW |
| Number of Poles | 4 Pole |
| AC1 Amperage | 450A |
| Barcode | 8013975312568 |
