BF26500E110 LOVATO MAXI 3P CONTACTOR 265A AC3 60-130VAC/DC

Why Choose the BF26500E110?

Designed for heavy‑duty motor control, the Lovato BF26500E110 three‑pole contactor delivers 265A AC‑3 performance at 400V (132 kW) with a robust AC/DC coil rated 60…130VAC/DC. Its 450A AC‑1 thermal rating and screw mounting make installation straightforward in industrial panels. With SKU BF26500E110, you get proven BF265 reliability for demanding AC‑3 switching and power distribution tasks.

Engineered for resilience, the BF265 offers 1000 V rated insulation and 8 kV impulse withstand, backed by 5,000,000 mechanical operations. It operates from −40 to 70 °C, up to 3000 m altitude, pollution degree 3. Rated 200 HP at 480 V (UL/CSA) and compliant with IEC/EN/BS 60947‑1/‑4‑1, UL and CSA standards, it suits rigorous industrial control environments.

Key Benefits

• High AC‑3 switching capacity: 265A at 400V, 132 kW output.
• Wide‑range AC/DC coil covering 60…130VAC/DC for flexible control voltages.
• Rugged insulation and impulse withstand: Ui 1000 V, Uimp 8 kV.
• Long mechanical life rated at 5,000,000 switching cycles.
• Operates from −40 to 70 °C; suitable up to 3000 m altitude.
• High terminal tightening torque (35 to 35 Nm) for secure connections.
• Global compliance: IEC/EN/BS, UL and CSA standards for assured compatibility.

Technical Specification

• Product type designation: BF265
• Number of poles: 3
• Rated insulation voltage Ui (IEC/EN): 1000 V
• Rated impulse withstand voltage Uimp: 8 kV
• Ith (IEC): 450 A
• Terminal tightening torque: 35 to 35 Nm
• Mechanical life: 5000000 cycles
• Operating temperature: -40 to 70 °C
• Storage temperature: -50 to 80 °C
• Max altitude: 3000 m
• Pollution degree: 3

What’s Included

• Lovato BF26500E110 three‑pole contactor (BF265)
• Factory‑fitted AC/DC coil, 60…130VAC/DC
• Manufacturer datasheet (downloadable)
• Conformity information per IEC/EN/BS, UL and CSA standards

Applications

• AC‑3 duty motor control at 400V up to 265A (132 kW).
• AC‑1 duty power switching up to 450A thermal current.
• Industrial control panels requiring IEC/EN/BS 60947 conformity.
• UL/CSA installations needing up to 200 HP at 480 V.
• Environments from −40 to 70 °C, up to 3000 m altitude.

Safety note: Install and commission only by qualified personnel. Isolate all power sources before work, follow the datasheet and applicable standards, and use the device strictly within its electrical and environmental ratings.
