BF1810L048 - 3P CONTACTOR 1NO 18A AC3 48VDC LOW C.

Why Choose the BF1810L048?

Engineered for reliable motor duty, the Lovato BF1810L048 three‑pole contactor combines a 48 V DC low‑consumption coil with AC‑3 performance of 18 A at 400 V (7.5 kW). Supplied with a built‑in 1NO auxiliary contact and screw or 35 mm DIN rail mounting, the BF1810L048 delivers compact, efficient switching for control panels and OEM machinery where low control power and strong IEC/EN 60947 compliance are essential.

Rated Ui 690 V and Uimp 6 kV, the BF18 series delivers robust insulation and surge withstand. This 32 A (AC‑1) device offers 10 HP at 480 V (UL/CSA), a mechanical life of 20,000,000 cycles, and operates from −50 to 70 °C up to 3000 m altitude. Screw terminals accept 1.5–1.8 Nm tightening; weight 500 g. Pollution degree 3, with 1NO auxiliary.

Key Benefits

• Low‑consumption 48 V DC coil reduces control power demand.
• 18 A AC‑3 at 400 V for reliable motor switching.
• Rated Ui 690 V and Uimp 6 kV for high insulation strength.
• Built‑in 1NO auxiliary contact simplifies signalling.
• Screw or 35 mm DIN rail mounting speeds installation.
• Wide −50 to 70 °C operating range suits harsh environments.
• Long 20,000,000‑cycle mechanical life enhances service reliability.
• Compliant with IEC/EN/BS, UL and CSA standards.

Technical Specification

• Product type designation: BF18
• Number of poles: 3
• Rated insulation voltage Ui (IEC/EN): 690 V
• Rated impulse withstand voltage Uimp: 6 kV
• Ith (IEC): 32 A
• Terminal tightening torque: 1.5 to 1.8 Nm
• Weight: 500 g
• Mechanical life: 20000000 cycles
• Operating temperature: -50 to 70 °C
• Storage temperature: -60 to 80 °C
• Max altitude: 3000 m
• Pollution degree: 3

What’s Included

• Lovato BF1810L048 three‑pole contactor (BF18 series)
• Pre‑fitted 48 V DC low‑consumption coil
• Integrated 1NO auxiliary contact
• Installation leaflet and manufacturer documentation

Applications

• AC‑3 motor duty switching up to 18 A at 400 V
• Resistive and general‑purpose loads up to 32 A (AC‑1)
• Control panels using 48 V DC control circuits
• DIN rail or screw‑mounted industrial assemblies
• Installations requiring IEC/EN/BS, UL and CSA compliance

Safety note: Installation and maintenance must be performed by qualified personnel. Isolate all power before work, observe specified tightening torques, and follow applicable standards and local regulations.
