BF1201D048 - 3P CONTACTOR 1NC 12A AC3 48VDC
MPN: BF1201D048
Special Price
£68.60
£57.17
Regular Price
£114.34
Why Choose the BF1201D048?
The Lovato BF1201D048 three-pole contactor is engineered for dependable control of motors and resistive loads in industrial panels. Rated AC-3 12A/5.7Kw at 400V with a 48V DC coil, it ensures fast, consistent operation. A built-in 1NC auxiliary contact with mirror contact function enhances diagnostic safety and interlocking. Versatile, it mounts via screws or on 35mm DIN rail to speed installation.
Built on the BF12 platform, this contactor offers 28A Ith (AC1), 690V Ui insulation and 6 kV impulse withstand for robust performance. It achieves 20,000,000 mechanical operations and operates from -50 to 70 °C, up to 3000 m altitude. Screw terminals (1.5 to 1.8 Nm) aid secure wiring. Conforms to IEC/EN/BS 60947-1 and 60947-4-1, plus UL and CSA equivalents.
Key Benefits
- AC-3 12A/5.7Kw at 400V for dependable motor load switching.
- 48V DC coil for precise control in automation panels.
- 1NC auxiliary with mirror contact enhances safety diagnostics.
- Wide operating temperature from -50 to 70 °C supports harsh sites.
- High insulation: Ui 690 V and 6 kV impulse withstand.
- Flexible mounting on screws or 35mm DIN rail.
- Long mechanical life of 20,000,000 cycles reduces downtime.
- Compliant with IEC/EN/BS, UL and CSA standards.
Technical Specification
- Product type designation: BF12
- Number of poles: 3
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 28 A
- Terminal tightening torque: 1.5 to 1.8 Nm
- Weight: 494 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to 70 °C
- Storage temperature: -60 to 80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BF1201D048 three-pole contactor with 48V DC coil
- Integrated 1NC auxiliary contact (mirror contact function)
- Screw terminals ready for wiring
- Basic installation and safety information
Applications
- Motor control circuits requiring AC-3 12A performance at 400V
- Resistive and general-purpose load switching up to 28A AC1
- Machine automation and industrial control panels
- DIN rail mounted assemblies and compact MCCs
Frequently Asked Questions
What is the coil voltage and type?
It has a 48V DC coil, suitable for DC control circuits.
Which auxiliary contacts are included?
It includes one built-in 1NC auxiliary contact with mirror contact function.
How can this contactor be mounted?
It supports screw mounting or 35mm DIN rail installation.
Which standards does it conform to?
IEC/EN/BS 60947-1 and 60947-4-1, UL 60947-1 and 60947-4-1, and CSA C22.2 n° 60947-1 and 60947-4-1.
What environmental limits does it support?
Operating temperature is -50 to 70 °C, with installation up to 3000 m altitude.
Safety note: Always isolate power before installation or maintenance. Wire to the stated torque, observe the specified current and voltage ratings, and follow applicable IEC/EN and local regulations.
| Manufacturer Part Number | BF1201D048 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975166130 |
| Coil Voltage | 48VDC |
