BF0040L048 - CONTROL RELAY 4NO 48VDC LOW CONSUMPTION
MPN: BF0040L048
Special Price
£76.28
£63.57
Regular Price
£127.13
Why Choose the BF0040L048?
Lovato's BF0040L048 is a panel-ready control relay designed for dependable automation switching. Featuring a low-consumption 48VDC coil and four normally open contacts, this 4-pole unit fits screw or 35mm DIN rail mounting. It delivers a rated insulation voltage of 690 V and impulse withstand of 6 kV, supporting robust performance across control circuits where efficient DC coil operation and clean contact closure are essential.
Built on the BF00 platform, it is rated Ith 10 A and tested for 20,000,000 mechanical cycles, providing long service in demanding panels. Operating from -50 to 70 °C and up to 3000 m altitude, with Pollution Degree 3 robustness, it meets IEC/EN 60947-1 and 60947-5-1, plus UL 60947-1, UL 60947-5-1 and CSA C22.2 n° 60947-1 / 60947-5-1. Terminals accept 1.5 to 1.8 Nm tightening for secure wiring.
Key Benefits
- Low-consumption 48VDC coil reduces control power demand.
- Four normally open contacts provide clear, simultaneous switching.
- 4-pole design suits versatile control circuit configurations.
- Rated insulation 690 V and 6 kV impulse withstand.
- High endurance: 20,000,000 mechanical cycles for long life.
- Wide operating temperature -50 to 70 °C for harsh environments.
- Mounts via screw or 35mm DIN rail for flexible installation.
- Ith 10 A supports robust auxiliary switching.
Technical Specification
- Product type designation: BF00
- Number of poles: 4
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 10 A
- Terminal tightening torque: 1.5 to 1.8 Nm
- Weight: 496 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to 70 °C
- Storage temperature: -60 to 80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BF0040L048 control relay
- Manufacturer datasheet and safety information
- Protective packaging for transit
Applications
- General industrial control circuits and automation panels
- Auxiliary switching and signalling in PLC-controlled systems
- Interlocks, permissives, and status relay functions
- Low-power DC coil applications with 48 V control supply
Frequently Asked Questions
What coil voltage and type does the BF0040L048 use?
It has a low-consumption 48 V DC coil for efficient control circuits.
How many and what type of contacts are provided?
It provides four normally open (4NO) contacts in a 4-pole configuration.
How is the relay mounted?
It mounts on 35 mm DIN rail or by screw, suiting varied panel layouts.
What are its principal electrical ratings?
Rated Ui is 690 V, impulse withstand Uimp 6 kV, with Ith 10 A.
What environmental and endurance ratings does it offer?
It operates from -50 to 70 °C and is rated for 20,000,000 mechanical cycles.
Safety note: Install and commission only by qualified personnel. Isolate the supply before wiring or maintenance, and follow IEC/EN 60947 standards, specified torque, and environmental limits.
| Manufacturer Part Number | BF0040L048 |
|---|---|
| Manufacturer | Lovato |
| Packed Quantity | 1 |
| HS Code | 85365080 |
| Barcode | 8013975167830 |
| Coil Voltage | 48VDC |
