BCG0524 - SWITCHING BATTERY CHARGER 5A 24VDC
MPN: BCG0524
Special Price
£300.24
£250.20
Regular Price
£500.41
Why Choose the BCG0524?
The Lovato BCG0524 automatic battery charger from the switching BCG series is designed for sealed and not sealed lead-acid batteries. Providing a 24VDC output at 5A with one charging level, it supports position voltages V1 27.6 and V2 27.0 as specified. Weighing 532 g, the BCG0524 offers dependable 24 V maintenance charging for industrial panels and standby systems.
Built for challenging environments, this Lovato BCG automatic battery charger operates from -30 to +55 °C and stores safely between -30 and +80 °C. Compliance with IEC/EN/BS 62368-1 and IEC/EN/BS 61000-6-2, plus UL 60950-1 and CSA C22.2 n°60950-1, supports safety and EMC requirements. Ideal for reliable 24VDC, 5A charging across industrial maintenance and backup duties.
Key Benefits
- 24VDC, 5A output for dependable lead-acid battery charging.
- Compatible with sealed and not sealed lead-acid batteries.
- Single charging level simplifies set-up and operation.
- Two position voltages: V1 27.6 and V2 27.0 available.
- Wide operating temperature range from -30 to +55 °C.
- Conforms to IEC/EN/BS and UL/CSA safety and EMC standards.
- Lightweight 532 g construction aids easy panel integration.
Technical Specification
- Product type designation: BCG
- Weight: 532 g
- Operating temperature: -30 to +55 °C
- Storage temperature: -30 to +80 °C
What’s Included
- Lovato BCG0524 automatic battery charger
- Quick start and safety information
- Product documentation reference
Applications
- Maintaining 24 V lead-acid batteries in control and automation panels
- Standby and backup battery charging for industrial equipment
- Charging 24 V lead-acid battery banks in instrumentation systems
- Power supply maintenance for security and alarm systems
Frequently Asked Questions
Is the Lovato BCG0524 compatible with sealed and not sealed lead-acid batteries?
Yes. It is designed for sealed and not sealed lead-acid batteries as specified.
What is the output rating of the BCG0524 charger?
It delivers a 24VDC output at 5A with one charging level.
What is the operating temperature range?
The operating range is -30 to +55 °C; storage is -30 to +80 °C.
Which safety and EMC standards does it comply with?
It conforms to IEC/EN/BS 62368-1, IEC/EN/BS 61000-6-2, UL 60950-1 and CSA C22.2 n°60950-1.
Can I use this charger with lithium batteries?
No. It is intended for lead-acid batteries only.
Safety note: Install and operate according to the manufacturer’s instructions, observing the stated voltage settings and temperature limits. Only qualified personnel should connect to mains and batteries.
| Manufacturer Part Number | BCG0524 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 8504405509 |
| Barcode | 8013975206621 |
