AX2394.400 Rittal AX Rail for interior installation, for D: 400 mm

Why Choose the Rittal AX 2830.400 Base/Plinth Side Elements?

The Rittal AX 2830.400 is a robust base/plinth side element set designed to provide structural stability and support for AX enclosure systems. As part of the modular plinth system, it enables enclosures to be elevated, improving cable management, airflow and overall installation efficiency.

Manufactured from high-quality sheet steel with a protective coating, this component is engineered for long-term durability in industrial environments. It integrates seamlessly with the Rittal AX platform, ensuring reliable alignment and structural integrity across installations.

Designed for enclosures with a depth of 400 mm and a compact plinth height of 100 mm, the AX 2830.400 is ideal for low-profile installations where space efficiency and stability are essential. Rittal plinth systems provide a stable base while creating additional space for cable entry.

Key Advantages

• Provides stable support for AX enclosure plinth systems.
• Enables raised installation for improved cable routing.
• 100 mm height ideal for compact, low-profile applications.
• Durable steel construction for industrial environments.
• Ensures precise enclosure alignment and stability.
• Fully compatible with Rittal AX enclosure systems.

Key Features

• Base/plinth side elements for AX enclosure systems.
• Height: 100 mm.
• Designed for 400 mm enclosure depth.
• Constructed from sheet steel with plastic cover caps.
• RAL 9005 black finish.
• Supplied with mounting and assembly components.
• 2-piece set for complete installation.

Technical Specifications

• Manufacturer: Rittal
• Series: AX Enclosure Accessories
• Model: AX 2830.400
• Product type: Base/plinth side component
• Material: Sheet steel (components), plastic (cover caps)
• Colour: RAL 9005
• Height: 100 mm
• Suitable enclosure depth: 400 mm
• Compatibility: Rittal AX enclosure systems
• Supply: 2 base/plinth components, cover caps, assembly parts
• Weight: approx. 2.5 kg

Improved Installation and Cable Management

The AX 2830.400 elevates enclosures above floor level, allowing easier cable entry, improved airflow and better accessibility for installation and maintenance. This contributes to cleaner system layouts and enhanced operational reliability.

Its rigid steel construction ensures secure mounting even in demanding industrial environments, making it suitable for control panels, automation systems and power distribution installations.

Typical Applications

• Industrial control panels and switchgear enclosures.
• Machine building and OEM installations.
• Power distribution cabinets.
• Automation and process control systems.
• Installations requiring compact plinth elevation.

Trusted by Panel Builders Worldwide

Rittal AX plinth systems are widely trusted by engineers and panel builders for delivering stable enclosure mounting, efficient cable management and reliable industrial installations.
