AX1008.000 Rittal AX Compact enclosure, WHD: 380x600x210 mm, stainless steel 1.4301

Why Choose the Rittal AX 1008.000 Stainless Steel Enclosure?

The Rittal AX 1008.000 is a compact and highly durable stainless steel enclosure designed for industrial control and automation applications. As part of the advanced AX enclosure platform, it delivers reliable protection, efficient installation and flexible internal configuration for modern panel building.

Constructed from stainless steel 1.4301 (AISI 304), this enclosure is ideal for corrosive, hygienic and outdoor environments. Its integrated locator system enables rapid installation of internal components without drilling, preserving the enclosure’s protection rating while significantly reducing assembly time.

With dimensions of 380 × 600 × 210 mm and a single-door configuration, the AX 1008.000 provides a vertical format ideal for control panels and automation systems where space efficiency and accessibility are essential.

Key Advantages

• Corrosion-resistant stainless steel construction for harsh environments.
• Tool-free internal configuration using integrated locator system.
• Maintains enclosure protection rating without drilling.
• Vertical format optimised for panel layouts.
• Reliable protection against dust, water and contaminants.
• Suitable for hygienic and industrial applications.

Key Features

• AX compact enclosure in stainless steel.
• Dimensions: 380 × 600 × 210 mm.
• Material: Stainless steel 1.4301 (AISI 304).
• Single-door design with approx. 130° opening angle.
• Two cam locks with 3 mm double-bit insert.
• Mounting plate included (zinc-plated sheet steel).
• Integrated 25 mm system pitch for modular accessories.

Technical Specifications

• Manufacturer: Rittal
• Series: AX Compact Enclosures
• Model: AX 1008.000
• Product type: Wall-mounted enclosure
• Material: Stainless steel 1.4301 (AISI 304)
• Surface finish: Brushed (grain 400)
• Dimensions (W × H × D): 380 × 600 × 210 mm
• Mounting plate size: approx. 330 × 575 mm
• Number of doors: 1
• Locking system: Cam locks, 3 mm double-bit
• Protection rating (IEC 60529): IP66
• NEMA rating: NEMA 4X / 12
• Impact resistance: IK10
• Weight: approx. 13 kg
• EAN: 4028177814974

Reliable Protection for Industrial Environments

The AX 1008.000 enclosure provides high protection against dust and water ingress thanks to its foamed-in PU gasket and sealed stainless steel construction. This ensures dependable performance in demanding industrial and hygienic environments.

Its modular AX system allows rapid installation of accessories and internal components without mechanical modification, enabling flexible configuration and future expansion while maintaining enclosure integrity.

Typical Applications

• Industrial control panels and automation systems.
• Machine building and OEM installations.
• Food and beverage processing environments.
• Pharmaceutical and cleanroom applications.
• Outdoor and corrosive industrial locations.

Trusted by Engineers Worldwide

Rittal AX compact enclosures are widely trusted by engineers and panel builders for delivering reliable protection, flexible configuration and long-term durability in industrial automation environments.
