AX1007.000 Rittal AX Compact enclosure, WHD: 500x500x210 mm, stainless steel 1.4301

Why Choose the Rittal AX 1007.000 Stainless Steel Enclosure?

The Rittal AX 1007.000 is a compact and highly durable stainless steel enclosure designed for industrial control and automation applications. As part of the AX enclosure platform, it provides reliable protection, efficient installation and flexible internal configuration for modern panel building.

Manufactured from stainless steel 1.4301 (AISI 304), this enclosure is ideal for corrosive, hygienic and outdoor environments. Its integrated locator system allows rapid installation of internal components without drilling, preserving the enclosure’s protection rating while reducing installation time.

With dimensions of 500 × 500 × 210 mm and a single-door configuration, the AX 1007.000 is well suited for machine-level control panels and compact automation systems where reliability and space efficiency are critical.

Key Advantages

• Corrosion-resistant stainless steel construction for harsh environments.
• Tool-free internal configuration using integrated locator system.
• Maintains enclosure protection rating without drilling.
• Compact design for efficient panel layouts.
• High protection against dust, water and contaminants.
• Suitable for hygienic and industrial applications.

Key Features

• AX compact enclosure in stainless steel.
• Dimensions: 500 × 500 × 210 mm.
• Material: Stainless steel 1.4301 (AISI 304).
• Single-door design with approx. 130° opening angle.
• Two cam locks with 3 mm double-bit insert.
• Mounting plate included (zinc-plated sheet steel).
• Integrated 25 mm system pitch for modular accessories.

Technical Specifications

• Manufacturer: Rittal
• Series: AX Compact Enclosures
• Model: AX 1007.000
• Product type: Wall-mounted enclosure
• Material: Stainless steel 1.4301 (AISI 304)
• Surface finish: Brushed (grain 400)
• Dimensions (W × H × D): 500 × 500 × 210 mm
• Mounting plate size: approx. 450 × 475 mm
• Number of doors: 1
• Locking system: Cam locks, 3 mm double-bit
• Protection rating (IEC 60529): IP66
• NEMA rating: NEMA 4X / 12
• Impact resistance: IK10
• Weight: approx. 14–16 kg
• EAN: 4028177814967

Reliable Protection for Industrial Environments

The AX 1007.000 enclosure provides excellent protection against dust and water ingress thanks to its foamed-in PU gasket and sealed stainless steel construction. This ensures dependable performance in demanding industrial and hygienic environments.

Its modular AX system platform enables rapid installation of accessories and internal components without mechanical modification, allowing flexible configuration and easy future expansion while maintaining enclosure integrity.

Typical Applications

• Industrial control panels and automation systems.
• Machine building and OEM installations.
• Food and beverage processing environments.
• Pharmaceutical and cleanroom applications.
• Outdoor and corrosive industrial locations.

Trusted by Engineers Worldwide

Rittal AX compact enclosures are widely trusted by engineers and panel builders for delivering reliable protection, flexible configuration and long-term durability in industrial automation environments.
