AX1005.000 Rittal AX Compact enclosure, WHD: 300x380x210 mm, stainless steel 1.4301

Why Choose the Rittal AX 1005.000 Stainless Steel Enclosure?

The Rittal AX 1005.000 is a compact and robust stainless steel enclosure engineered for industrial control and automation applications. As part of the advanced AX enclosure platform, it delivers reliable protection, efficient installation and flexible internal configuration for modern panel building.

Manufactured from stainless steel 1.4301 (AISI 304), this enclosure is ideal for corrosive, hygienic and outdoor environments. Its integrated locator system allows rapid installation of internal components without drilling, maintaining enclosure integrity while reducing assembly time.

With compact dimensions of 300 × 380 × 210 mm and a single-door configuration, the AX 1005.000 is perfectly suited for machine-level control panels and small automation systems where space efficiency and durability are essential.

Key Advantages

• Corrosion-resistant stainless steel construction for harsh environments.
• Tool-free internal configuration using integrated locator system.
• Maintains enclosure protection rating without drilling.
• Compact design ideal for space-limited installations.
• High protection against dust and water ingress.
• Suitable for hygienic and industrial applications.

Key Features

• AX compact enclosure in stainless steel.
• Dimensions: 300 × 380 × 210 mm.
• Material: Stainless steel 1.4301 (AISI 304).
• Single-door design with approx. 130° opening angle.
• Cam lock with 3 mm double-bit insert.
• Mounting plate included (zinc-plated sheet steel).
• Integrated 25 mm system pitch for modular accessories.

Technical Specifications

• Manufacturer: Rittal
• Series: AX Compact Enclosures
• Model: AX 1005.000
• Product type: Wall-mounted enclosure
• Material: Stainless steel 1.4301 (AISI 304)
• Surface finish: Brushed (grain 400)
• Dimensions (W × H × D): 300 × 380 × 210 mm
• Mounting plate size: approx. 250 × 355 mm
• Number of doors: 1
• Locking system: Cam lock, 3 mm double-bit
• Protection rating (IEC 60529): IP66
• NEMA rating: NEMA 4X / 12
• Impact resistance: IK10
• Material thickness: enclosure approx. 1.25 mm, door approx. 1.5 mm
• Weight: approx. 7 kg
• EAN: 4028177814943

Compact Protection for Industrial Environments

The AX 1005.000 enclosure provides reliable protection against dust and water ingress thanks to its foamed-in PU gasket and sealed stainless steel construction. This ensures dependable operation in demanding industrial and hygienic environments.

Its modular AX system platform enables rapid installation of accessories and internal components without mechanical modification, allowing flexible configuration and future expansion while maintaining enclosure integrity.

Typical Applications

• Machine-level control panels and automation systems.
• Small industrial control installations.
• Food and beverage processing environments.
• Pharmaceutical and cleanroom applications.
• Outdoor and corrosive industrial locations.
