IOS/M08IVX-D1 IMO Remote I/O module, RS485 (HD) 8 A/D Input (Voltage) 16-bit
MPN: IOS/M08IVX-D1
Alt. SKU: IOSM08IVXD1
Special Price
£331.99
£276.66
Regular Price
£405.42
IOS/M08IVX-D1 IMO Remote I/O module, RS485 (HD) 8 A/D Input (Voltage) 16-bit is available to buy in increments of 1
Why Choose the IMO IOS/M08IVX-D1 Analog Voltage Input Module?
The IOS/M08IVX-D1 remote I/O module provides eight high-accuracy analog voltage inputs over an RS-485 Modbus RTU network. With a configurable 0–10 V (or 0–5 V) input range and 12-bit resolution, it brings precise signal acquisition directly to remote panels, minimizing cable runs and central I/O card requirements in distributed control systems.
Key Features of the IOS/M08IVX-D1 Module
- 8 Analog Inputs: 0–10 V DC (configurable to 0–5 V) with 12-bit (4096-step) resolution.
- Input Impedance: 100 kΩ typical for minimal loading of signal sources.
- Modbus RTU Interface: RS-485 half-duplex bus, supports up to 32 nodes per segment.
- Operating Voltage: 20.4–28.8 V DC nominal panel power.
- Form Factor: 176.6 × 50 × 39 mm; DIN-rail mountable IP20 enclosure.
- Diagnostics: LEDs for power, communication activity, and per-channel input status.
Frequently Asked Questions About the IOS/M08IVX-D1
- What voltage ranges are supported?
- How do I configure input scaling?
- Can I measure 4–20 mA signals with this module?
- Which Modbus registers map to the inputs?
- Is the module hot-swappable?
How to Install the IOS/M08IVX-D1 Module
Mount the IOS/M08IVX-D1 onto a 35 mm DIN rail. Connect 20.4–28.8 V DC to the power terminals. Wire analog voltage signals to the eight input terminals, observing polarity. Terminate and daisy-chain the RS-485 bus to the Modbus port, set the device address and baud rate via DIP switches, and power up. Verify input readings and communication by checking the LEDs.
IMO IOS/M08IVX-D1 – 8 × 0–10 V Analog Inputs via Modbus RTU
The IOS/M08IVX-D1 expands your Modbus RTU network with precise analog voltage measurement capabilities. Its 12-bit ADC and configurable input ranges ensure accurate reading of sensors, transducers, and other DC signal sources. Robust isolation and surge protection maintain signal integrity in harsh industrial environments.
Designed for panel-mount and remote I/O applications, the module features straightforward wiring, reliable LED diagnostics, and a compact DIN-rail profile to simplify system integration and maintenance.
Frequently Asked Questions
The module supports 0–10 V DC by default; it can be configured for 0–5 V ranges via software registers.
Use your Modbus RTU master to write scaling parameters to the configuration registers; settings are stored in non-volatile memory.
Yes—by installing a 250 Ω shunt resistor across each input, 4–20 mA loops convert to 1–5 V for direct measurement.
Analog input values are available in Input Registers starting at address 30001; consult the datasheet for the exact register map.
No—power down the RS-485 network before inserting or removing the IOS/M08IVX-D1 to avoid communication errors.
