ABB S203MT-Z6 MCB - S200M - 3P - Z - 6
MPN: 2CDS273445R0378
Alt. SKU: S203MT-Z6
Special Price
£181.15
£150.96
Regular Price
£241.54
Why Choose the S203MT-Z6 [2CDS273445R0378]
S203MT-Z6 Miniature Circuit Breaker Z-Char., 10kA, 6A, 3P
Technical Specification
- Product Name: S203MT-Z6 Miniature Circuit Breaker, 3-pole.
- Rated Current: 6 A.
- Breaking Capacity: 15 kA ultimate short-circuit breaking capacity at 230/400 V.
- Service Short-Circuit Capacity (Ics): 11.2 kA.
- Number of Poles: 3 poles with 3 modular widths (DIN 43880 size 3).
- Terminal Type: Screw terminals with failsafe bi-directional cylinder-lift design.
- Connecting Capacity: Flexible 0.75–25 mm², rigid and stranded up to 35 mm².
- Dielectric Test Voltage: 2 kV, 50/60 Hz for 1 minute.
- Mechanical Endurance: 20,000 operating cycles.
- Actuator: Toggle type, black insulated, sealable.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the rated current of the S203MT-Z6 Miniature Circuit Breaker?
The rated current is 6 A.
What is the breaking capacity of this circuit breaker?
The ultimate short-circuit breaking capacity is 15 kA at 230/400 V.
How many poles does the S203MT-Z6 have?
It has 3 poles.
What is the connecting capacity for cables?
It supports flexible cables from 0.75–25 mm² and rigid or stranded cables up to 35 mm².
What type of terminals does this circuit breaker use?
It uses screw terminals with a failsafe bi-directional cylinder-lift design.
What is the mechanical endurance of the S203MT-Z6?
The mechanical endurance is rated for 20,000 operating cycles.
What standards and approvals does this product conform to?
See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CDS273445R0378 |
|---|---|
| Amperage | 3A |
| Number of Poles | 3 Pole |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
| Manufacturer | ABB |
| Alternative Product SKU | S203MT-Z6 |
| Barcode | 4016779127981 |
