ABB S203MT-K32 MCB - S200P - 3P - K - 32A
MPN: 2CDS273445R0537
Alt. SKU: S203MT-K32
Special Price
£184.32
£153.60
Regular Price
£245.76
Why Choose the S203MT-K32 [2CDS273445R0537]
S203MT-K32 Miniature Circuit Breaker K-Char., 10kA, 32A, 3P
Technical Specification
- Function: Miniature Circuit Breaker, Type K Characteristic.
- Rated Current: 32 A.
- Poles: 3P (Three Pole) with 3 protected poles.
- Rated Voltage: 230/400 V AC.
- Short-Circuit Breaking Capacity: 15 kA (ultimate) at 230/400 V; 11.2 kA (service).
- Dielectric Test Voltage: 2 kV, 50/60 Hz, 1 minute.
- Terminal Type and Capacity: Failsafe bi-directional screw terminals, suitable for flexible cables 0.75–25 mm², rigid and stranded cables up to 35 mm², busbar 10/10 mm².
- Mechanical Endurance: 20,000 operating cycles.
- Installation Width: 3 modular units (DIN 43880 standard).
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the rated current of the S203MT-K32 Miniature Circuit Breaker?
The rated current is 32 A.
What is the short-circuit breaking capacity of this circuit breaker?
The short-circuit breaking capacity is 15 kA (ultimate) at 230/400 V and 11.2 kA (service).
What types of cables can be connected to this circuit breaker?
It is suitable for flexible cables from 0.75 to 25 mm², and rigid and stranded cables up to 35 mm².
How many poles does the S203MT-K32 have?
This circuit breaker has 3 poles (3P).
What is the installation width of the circuit breaker?
The installation width is 3 modular units according to the DIN 43880 standard.
What is the dielectric test voltage for this product?
The dielectric test voltage is 2 kV at 50/60 Hz for 1 minute.
What is the mechanical endurance of the S203MT-K32?
The mechanical endurance is rated at 20,000 operating cycles.
| Manufacturer Part Number | 2CDS273445R0537 |
|---|---|
| Amperage | 32A |
| Number of Poles | 3 Pole |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
| Manufacturer | ABB |
| Alternative Product SKU | S203MT-K32 |
| Barcode | 4016779126724 |
