ABB S203MT-C25NA MCB - S200M - 4P - C - 25A
MPN: 2CDS273446R0254
Alt. SKU: S203MT-C25NA
Special Price
£156.70
£130.58
Regular Price
£208.92
Why Choose the S203MT-C25NA [2CDS273446R0254]
S203MT-C25NA Miniature Circuit Breaker C-Char., 10kA, 25A, 3P, +NA
Technical Specification
- Function: Miniature Circuit Breaker, C-Characteristic.
- Rated Current: 25 A.
- Poles: 3P + Neutral (4 modules wide).
- Breaking Capacity: 15 kA at 230/400 V AC.
- Rated Service Short-Circuit Breaking Capacity (Ics): 11.2 kA.
- Dielectric Test Voltage: 2 kV, 50/60 Hz for 1 minute.
- Terminal Type and Capacity: Screw terminals; busbar 10/10 mm²; flexible 0.75–25 mm²; rigid 0.75–35 mm².
- Mechanical Endurance: 20,000 cycles.
- Actuator: Toggle, black insulation, sealable, marked I/O.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the rated current of the S203MT-C25NA Miniature Circuit Breaker?
The rated current is 25 A.
What is the breaking capacity of this circuit breaker?
The breaking capacity is 15 kA at 230/400 V AC.
How many poles does the S203MT-C25NA have?
It has 3 poles plus a neutral (3P + N).
What is the terminal type and capacity for this circuit breaker?
It features screw terminals with a busbar capacity of 10/10 mm², flexible capacity of 0.75–25 mm², and rigid capacity of 0.75–35 mm².
What is the mechanical endurance of the S203MT-C25NA?
The mechanical endurance is 20,000 cycles.
What type of actuator does this circuit breaker use?
It uses a toggle actuator with black insulation, which is sealable and marked I/O.
What standards and approvals does this product conform to?
See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CDS273446R0254 |
|---|---|
| Amperage | 25A |
| Number of Poles | 4 Pole |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
| Manufacturer | ABB |
| Alternative Product SKU | S203MT-C25NA |
| Barcode | 4016779124249 |
