ABB S203MT-C10NA MCB - S200M - 4P - C - 10A
MPN: 2CDS273446R0104
Alt. SKU: S203MT-C10NA
Special Price
£120.71
£100.59
Regular Price
£160.94
Why Choose the S203MT-C10NA [2CDS273446R0104]
S203MT-C10NA Miniature Circuit Breaker C-Char., 10kA, 10A, 3P, +NA
Technical Specification
- Function: Miniature Circuit Breaker, C-Characteristic.
- Rated Current: 10 A.
- Poles: 3P+N (3 protected poles plus neutral).
- Rated Ultimate Short-Circuit Breaking Capacity (Icu): 15 kA at 230/400 V.
- Rated Service Short-Circuit Breaking Capacity (Ics): 11.2 kA.
- Dielectric Test Voltage: 2 kV, 50/60 Hz, 1 minute.
- Terminal Type: Screw terminals with failsafe bi-directional cylinder-lift design.
- Connecting Capacity: Busbar 10 mm²; flexible cables with ferrule 0.75–16 mm²; flexible 0.75–25 mm²; rigid & stranded 0.75–35 mm².
- Mechanical Endurance: 20,000 cycles.
- Actuator: Toggle, insulation group II, sealable with I/O marking.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the rated current of the S203MT-C10NA Miniature Circuit Breaker?
The rated current is 10 A.
How many poles does the S203MT-C10NA have?
It has 3 protected poles plus a neutral (3P+N).
What is the rated ultimate short-circuit breaking capacity of this circuit breaker?
The rated ultimate short-circuit breaking capacity (Icu) is 15 kA at 230/400 V.
What types of cables can be connected to the S203MT-C10NA?
It can connect busbars of 10 mm², flexible cables with ferrules from 0.75–16 mm², flexible cables from 0.75–25 mm², and rigid & stranded cables up to 0.75–35 mm².
What is the mechanical endurance of the S203MT-C10NA?
The mechanical endurance is rated for 20,000 cycles.
What is the dielectric test voltage for this circuit breaker?
The dielectric test voltage is 2 kV, 50/60 Hz for 1 minute.
What standards and approvals does the S203MT-C10NA comply with?
See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CDS273446R0104 |
|---|---|
| Amperage | 10A |
| Number of Poles | 4 Pole |
| Manufacturer | ABB |
| Alternative Product SKU | S203MT-C10NA |
| Barcode | 4016779124195 |
