ABB S203M-K2NA MCB - S200P - 4P - K - 2A
MPN: 2CDS273103R0277
Alt. SKU: S203M-K2NA
Special Price
£119.12
£99.27
Regular Price
£216.59
Why Choose the S203M-K2NA [2CDS273103R0277]
System pro M compact S200M miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 10 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200M comply with IEC/EN 60898-1 and IEC/EN 609 47-2, allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200M to save 50% space.
Technical Specification
- Function: Thermal and electromechanic trip mechanisms for overload and short circuit protection.
- Rated Voltage: Up to 440 V AC.
- Rated Current: Up to 63 A.
- Contact Configuration: 3 poles plus neutral (3P+N).
- Breaking Capacity: 25 kA at 230 V AC, 15 kA at 400/440 V AC.
- Insulation/Dielectric Rating: 2 kV dielectric test voltage (50/60 Hz, 1 min).
- Terminal Type and Size Range: Screw terminals; flexible 0.75–25 mm², rigid 0.75–35 mm², busbar 10/10 mm².
- Mechanical Endurance: 20,000 operating cycles.
- Contact Position Indication: Red ON / Green OFF.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What types of tripping mechanisms do the S200M miniature circuit breakers use?
The S200M miniature circuit breakers utilise a delayed thermal tripping mechanism for overload protection and an electromechanic tripping mechanism for short circuit protection.
What is the maximum breaking capacity of the S200M circuit breakers?
The S200M circuit breakers have a breaking capacity of up to 25 kA at 230 V AC and 15 kA at 400/440 V AC.
What is the rated current range for the S200M circuit breakers?
The rated current for the S200M circuit breakers is up to 63 A.
Can auxiliary contacts be mounted on the S200M circuit breakers?
Yes, bottom-fitting auxiliary contacts can be mounted on the S200M circuit breakers, allowing for a space saving of 50%.
What terminal types and sizes are compatible with the S200M circuit breakers?
The S200M circuit breakers feature screw terminals compatible with flexible cables from 0.75–25 mm², rigid cables from 0.75–35 mm², and busbars of 10/10 mm².
What insulation rating do the S200M circuit breakers have?
The S200M circuit breakers have a dielectric test voltage rating of 2 kV (50/60 Hz, 1 min).
Are the S200M circuit breakers compliant with any standards?
Yes, all MCBs of the S200M product range comply with IEC/EN 60898-1 and IEC/EN 60947-2. See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CDS273103R0277 |
|---|---|
| Amperage | 2A |
| Number of Poles | 4 Pole |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
| Manufacturer | ABB |
| Alternative Product SKU | S203M-K2NA |
| Barcode | 4016779659475 |
