ABB S203-K3 MCB - S200P - 3P - K - 3A
MPN: 2CDS253001R0317
Alt. SKU: S203-K3
Special Price
£78.89
£65.74
Regular Price
£143.44
Why Choose the S203-K3 [2CDS253001R0317]
System pro M compact S200 miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 6 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200 comply with IEC/EN 60898-1, IEC/EN 60947-2, UL1077 allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200 to save 50% space.
Technical Specification
- Function: 3-pole miniature circuit breaker for overload and short circuit protection with thermal and electromechanical tripping mechanisms.
- Rated Current: Up to 63 A (model specific: S203-K3 rated at 3 A).
- Voltage Ratings: 230 V AC / 400 V AC / 440 V AC.
- Breaking Capacity: Ultimate breaking capacity up to 20 kA at 230 V AC, 10 kA at 400/440 V AC; Service breaking capacity up to 15 kA at 230 V AC, 7.5 kA at 400/440 V AC.
- Contact Configuration: 3 poles (3P).
- Terminal Type: Screw terminals with failsafe bi-directional cylinder-lift mechanism.
- Connecting Capacity: Busbar 10 mm²; conductor sizes 0.75 to 35 mm² (flexible, rigid, stranded).
- Electrical Endurance: 20,000 AC cycles; Mechanical Endurance: 20,000 cycles.
- Contact Position Indication: Red ON / Green OFF.
- Dielectric Test Voltage: 2 kV at 50/60 Hz for 1 minute.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the maximum rated current for the S200 miniature circuit breakers?
The maximum rated current for the S200 miniature circuit breakers is up to 63 A, depending on the model.
What are the available configurations for the S200 circuit breakers?
The S200 circuit breakers are available in configurations of 1P, 1P+N, 2P, 3P, 3P+N, and 4P.
What is the breaking capacity of the S200 circuit breakers?
The ultimate breaking capacity is up to 20 kA at 230 V AC and 10 kA at 400/440 V AC.
Can auxiliary contacts be mounted on the S200 circuit breakers?
Yes, bottom-fitting auxiliary contacts can be mounted on the S200 to save 50% space.
What types of conductors can be connected to the S200 circuit breakers?
The S200 circuit breakers can connect conductors sized from 0.75 to 35 mm², including flexible, rigid, and stranded types.
What standards do the S200 circuit breakers comply with?
All S200 circuit breakers comply with IEC/EN 60898-1, IEC/EN 60947-2, and UL1077. See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CDS253001R0317 |
|---|---|
| Amperage | 3A |
| Number of Poles | 3 Pole |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
| Manufacturer | ABB |
| Alternative Product SKU | S203-K3 |
| Barcode | 4016779507509 |
