ABB S203-K1.6 MCB - S200P - 3P - K - 1.6A

Why Choose the S203-K1.6 [2CDS253001R0257]

System pro M compact S200 miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 6 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200 comply with IEC/EN 60898-1, IEC/EN 60947-2, UL1077 allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200 to save 50% space.

Technical Specification

• Function: 3-pole miniature circuit breaker with thermal overload and electromechanical short circuit tripping.
• Rated Current: Up to 63A (model S203-K1.6 rated for 1.6A).
• Voltage Ratings: 230/400 V AC, max operating voltage up to 480Y/277 V AC (UL/CSA).
• Breaking Capacity: Ultimate up to 20 kA at 230 V AC, 10 kA at 400 V AC; Service breaking capacity 15 kA at 230 V AC, 7.5 kA at 400 V AC.
• Contact Configuration: 3 poles (3P) with toggle actuator and ON/OFF indication.
• Terminal Type and Capacity: Screw terminals with bi-directional cylinder lift; suitable for flexible 0.75–25 mm² and rigid up to 35 mm² conductors.
• Electrical Endurance: 20,000 AC cycles.
• Dielectric Test Voltage: 2 kV at 50/60 Hz for 1 minute.
• Tightening Torque: 2.8 N·m (UL/CSA 18 in·lb).
• Energy Limiting Class: Class 3 (IEC/EN standards compliant).
