ABB S203-B13NA MCB - S200P - 4P - B - 13A
MPN: 2CDS253103R0135
Alt. SKU: S203-B13NA
Special Price
£107.18
£89.32
Regular Price
£194.88
Why Choose the S203-B13NA [2CDS253103R0135]
System pro M compact S200 miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 6 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200 comply with IEC/EN 60898-1, IEC/EN 60947-2, UL1077 allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200 to save 50% space.
Technical Specification
- Function: Miniature circuit breaker with thermal and electromechanical tripping for overload and short circuit protection.
- Rated Voltage: Up to 440 V AC, suitable for 230/400 V AC systems.
- Rated Current: Up to 63 A, this model is rated at 13 A.
- Contact Configuration: 3 poles + neutral (3P+N).
- Breaking Capacity: Ultimate short-circuit breaking capacity 20 kA (230 V AC), 10 kA (400 V AC), service breaking capacity 15 kA (230 V AC), 7.5 kA (400 V AC).
- Impulse Withstand Voltage: Dielectric test voltage 2 kV (50/60 Hz, 1 min).
- Terminal Type and Capacity: Screw terminals, suitable for flexible and rigid conductors 0.75 to 35 mm², busbars up to 10 mm².
- Mechanical and Electrical Endurance: 20,000 cycles each.
- Actuator: Toggle type with red ON / green OFF indication, sealable.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the function of the System pro M compact S200 miniature circuit breakers?
They provide overload protection through a delayed thermal tripping mechanism and short circuit protection via an electromechanical tripping mechanism.
What are the available configurations for the S200 circuit breakers?
Configurations include 1P, 1P+N, 2P, 3P, 3P+N, and 4P.
What is the maximum breaking capacity of the S200 circuit breakers?
The ultimate short-circuit breaking capacity is 20 kA at 230 V AC and 10 kA at 400 V AC.
What is the rated current for this model of the S200 circuit breaker?
This model is rated at 13 A, with a maximum rated current of up to 63 A available in the range.
What is the terminal capacity for the S200 circuit breakers?
They have screw terminals suitable for flexible and rigid conductors from 0.75 to 35 mm², and busbars up to 10 mm².
Can auxiliary contacts be mounted on the S200 circuit breakers?
Yes, a bottom-fitting auxiliary contact can be mounted to save 50% space.
What standards do the S200 circuit breakers comply with?
They comply with IEC/EN 60898-1, IEC/EN 60947-2, and UL1077. See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CDS253103R0135 |
|---|---|
| Amperage | 13A |
| Number of Poles | 4 Pole |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
| Manufacturer | ABB |
| Alternative Product SKU | S203-B13NA |
| Barcode | 4016779532303 |
