ABB S202M-C13UC MCB - S200M - 2P - C - 13A
MPN: 2CDS272061R0134
Alt. SKU: S202M-C13UC
Special Price
£184.49
£153.74
Regular Price
£245.99
Why Choose the S202M-C13UC [2CDS272061R0134]
The miniature circuit breaker S 200 M UC extends the established ABB System pro M compact® product range with an MCB for DC and AC applications. The S 200 M UC impresses with its performance range and the accordingly large amount of approvals. Its high inbuilt short circuit breaking capacity across the entire model line, its flexible AC and DC application and its approval and compliance in accordance with all major international and local standards make it truly unique. All current System pro M compact® accessories can be combined easily with the new model line. Whether warehousing or project engineering, planning, installing or maintaining your equipment, the S 200 M UC is a simple and flexible solution.
Technical Specification
- Function: Miniature circuit breaker for DC and AC applications.
- Rated Voltage: Up to 500 V DC and 480Y/277 V AC.
- Breaking Capacity (Icu): Up to 25 kA at 220 V DC, 15 kA at 230/400 V AC.
- Contact Configuration: 2 poles (2P) with red ON / green OFF indication.
- Terminal Type and Capacity: Screw terminals; flexible cables 0.75–25 mm², rigid up to 35 mm².
- Mechanical and Electrical Endurance: 20,000 cycles each.
- Insulation and Dielectric Strength: Rated for 2 kV dielectric test voltage (50/60 Hz, 1 min).
- Tightening Torque: 2.8 N·m (standard), 25 in·lb (UL/CSA).
- Actuator: Toggle type, black, sealable with I/O marking.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What applications is the S 200 M UC suitable for?
The S 200 M UC is designed for both DC and AC applications, making it versatile for various electrical systems.
What is the rated voltage for the S 200 M UC?
The rated voltage is up to 500 V DC and 480Y/277 V AC.
What is the breaking capacity of the S 200 M UC?
The breaking capacity is up to 25 kA at 220 V DC and 15 kA at 230/400 V AC.
What is the terminal capacity for cable connections?
The S 200 M UC has screw terminals that accommodate flexible cables from 0.75 to 25 mm² and rigid cables up to 35 mm².
How many cycles can the S 200 M UC endure mechanically and electrically?
The device is rated for 20,000 cycles for both mechanical and electrical endurance.
What is the tightening torque specification for the terminals?
The standard tightening torque is 2.8 N·m (25 in·lb for UL/CSA).
What standards and approvals does the S 200 M UC comply with?
See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CDS272061R0134 |
|---|---|
| Amperage | 13A |
| Number of Poles | 2 Pole |
| Country of Manufacture | Germany |
| Manufacturer | ABB |
| Alternative Product SKU | S202M-C13UC |
| Barcode | 4013614433009 |
