ABB S202-Z3 MCB - S200P - 2P - Z - 3A
MPN: 2CDS252001R0318
Alt. SKU: S202-Z3
Special Price
£70.72
£58.93
Regular Price
£128.57
Why Choose the S202-Z3 [2CDS252001R0318]
System pro M compact S200 miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 6 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200 comply with IEC/EN 60898-1, IEC/EN 60947-2, UL1077 allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200 to save 50% space.
Technical Specification
- Function: Miniature circuit breaker with thermal and electromechanic tripping for overload and short circuit protection.
- Rated Current: Up to 63 A.
- Voltage Rating: Up to 480 Y / 277 V AC, 110 V DC.
- Contact Configuration: 2 poles (2P).
- Breaking Capacity: Up to 20 kA (230 V AC), 15 kA service short-circuit (230 V AC).
- Terminal Type: Screw terminals, failsafe bi-directional cylinder-lift.
- Connecting Capacity: Flexible and rigid cables 0.75 to 35 mm², busbar 10/10 mm².
- Mechanical and Electrical Endurance: 20,000 cycles each.
- Insulation and Dielectric Strength: Rated for 2 kV dielectric test voltage at 50/60 Hz for 1 minute.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the maximum rated current for the S200 miniature circuit breakers?
The maximum rated current for the S200 miniature circuit breakers is up to 63 A.
What types of tripping mechanisms are used in the S200 circuit breakers?
The S200 circuit breakers utilise a delayed thermal tripping mechanism for overload protection and an electromechanic tripping mechanism for short circuit protection.
What is the breaking capacity of the S200 circuit breakers?
The breaking capacity is up to 20 kA at 230 V AC and 15 kA for service short-circuit at 230 V AC.
What cable sizes are compatible with the S200 circuit breakers?
The S200 circuit breakers can accommodate flexible and rigid cables from 0.75 to 35 mm², and busbar of 10/10 mm².
Can auxiliary contacts be mounted on the S200 circuit breakers?
Yes, bottom-fitting auxiliary contacts can be mounted on the S200 to save 50% space.
What standards do the S200 circuit breakers comply with?
All MCBs of the S200 range comply with IEC/EN 60898-1, IEC/EN 60947-2, and UL1077. See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CDS252001R0318 |
|---|---|
| Amperage | 3A |
| Number of Poles | 2 Pole |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
| Manufacturer | ABB |
| Alternative Product SKU | S202-Z3 |
| Barcode | 4016779530712 |
