ABB S202-K63 MCB - S200P - 2P - K - 63A
MPN: 2CDS252001R0607
Alt. SKU: S202-K63
Special Price
£69.65
£58.04
Regular Price
£126.64
Why Choose the S202-K63 [2CDS252001R0607]
System pro M compact S200 miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 6 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200 comply with IEC/EN 60898-1, IEC/EN 60947-2, UL1077 allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200 to save 50% space.
Technical Specification
- Function: Current limiting miniature circuit breaker with thermal and electromechanical tripping for overload and short circuit protection.
- Voltage Ratings: Rated for up to 480Y/277 V AC and 110 V DC operation.
- Current Rating: Up to 63 A rated current (Model S202-K63 is 63 A).
- Contact Configuration: 2 poles (2P) for dual pole protection.
- Breaking Capacity: Ultimate breaking capacity up to 20 kA (230 V AC), service breaking capacity up to 15 kA (230 V AC).
- Terminal Type and Size Range: Failsafe, bi-directional screw terminals; accommodates rigid and flexible conductors from 0.75 to 35 mm².
- Mechanical & Electrical Endurance: 20,000 mechanical cycles, 10,000 electrical AC cycles.
- Actuator: Toggle type with red ON / green OFF indication; toggle sealable.
- Insulation & Dielectric Strength: Dielectric test voltage 2 kV at 50/60 Hz for 1 minute; Insulation Group II material.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What are the tripping mechanisms used in the S200 miniature circuit breakers?
The S200 miniature circuit breakers utilise a delayed thermal tripping mechanism for overload protection and an electromechanical tripping mechanism for short circuit protection.
What is the maximum breaking capacity of the S200 circuit breakers?
The ultimate breaking capacity is up to 20 kA at 230 V AC, with a service breaking capacity of up to 15 kA at the same voltage.
What is the range of rated currents available for the S200 series?
The S200 series offers rated currents up to 63 A, with the model S202-K63 specifically rated at 63 A.
What types of conductors can be used with the S200 circuit breakers?
The S200 circuit breakers accommodate rigid and flexible conductors ranging from 0.75 to 35 mm².
Can auxiliary contacts be mounted on the S200 circuit breakers?
Yes, a bottom-fitting auxiliary contact can be mounted on the S200 to save 50% space.
What standards do the S200 circuit breakers comply with?
All MCBs in the S200 range comply with IEC/EN 60898-1, IEC/EN 60947-2, and UL1077. See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CDS252001R0607 |
|---|---|
| Amperage | 63A |
| Number of Poles | 2 Pole |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
| Manufacturer | ABB |
| Alternative Product SKU | S202-K63 |
| Barcode | 4016779551175 |
