ABB s201m-d1 mcb s200m 1 pole d type 1a
MPN: 2CDS271001R0011
Alt. SKU: S201M-D1
Special Price
£17.75
£14.79
Regular Price
£32.27
Why Choose the S201M-D1 [2CDS271001R0011]
System pro M compact S200M miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 10 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200M comply with IEC/EN 60898-1 and IEC/EN 609 47-2, allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200M to save 50% space.
Technical Specification
- Function: Miniature Circuit Breaker with thermal and electromechanical tripping for overload and short circuit protection.
- Rated Current: Up to 63A.
- Voltage Ratings: 230/400 V AC; maximum operating voltage 480Y/277 V AC, 60 V DC.
- Breaking Capacity: Up to 25 kA (133 V AC), 15 kA (230/400 V AC), interrupting rating UL/CSA up to 10 kA (60 V DC).
- Contact Configuration: 1 pole (1P).
- Terminal Type and Capacity: Screw terminals; busbar 10/10 mm², flexible and rigid cables 0.75 to 35 mm².
- Mechanical Durability: 20,000 mechanical cycles.
- Electrical Endurance: 20,000 AC cycles.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the maximum rated current for the S200M miniature circuit breakers?
The maximum rated current for the S200M miniature circuit breakers is up to 63A.
What are the available breaking capacities for the S200M?
The S200M has breaking capacities of up to 25 kA (133 V AC) and 15 kA (230/400 V AC), with an interrupting rating of up to 10 kA (60 V DC).
What types of cables can be used with the S200M circuit breakers?
The S200M circuit breakers can accommodate flexible and rigid cables ranging from 0.75 to 35 mm².
Can auxiliary contacts be mounted on the S200M circuit breakers?
Yes, bottom-fitting auxiliary contacts can be mounted on the S200M to save 50% space.
What tripping mechanisms are used in the S200M circuit breakers?
The S200M circuit breakers utilise a delayed thermal tripping mechanism for overload protection and an electromechanical tripping mechanism for short circuit protection.
What standards do the S200M circuit breakers comply with?
All MCBs of the S200M range comply with IEC/EN 60898-1 and IEC/EN 60947-2. See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CDS271001R0011 |
|---|---|
| Amperage | 1A |
| Number of Poles | 1 Pole |
| Trip Curve Type | Type B 10KA |
| Manufacturer | ABB |
| Alternative Product SKU | S201M-D1 |
| Barcode | 4016779599313 |
| Product Lead Time | Please contact us for a delivery time |
