ABB S201M-D0.5NA MCB - S200M - 2P - D - 0.5A
MPN: 2CDS271103R0981
Alt. SKU: S201M-D0.5NA
Special Price
£45.05
£37.54
Regular Price
£81.90
Why Choose the S201M-D0.5NA [2CDS271103R0981]
System pro M compact S200M miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 10 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200M comply with IEC/EN 60898-1 and IEC/EN 609 47-2, allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200M to save 50% space.
Technical Specification
- Function: Miniature circuit breaker with thermal and electromechanical tripping for overload and short circuit protection.
- Rated Voltage: Up to 400 V AC (480Y/277 V AC UL/CSA) and 60 V DC.
- Breaking Capacity: Up to 25 kA (133 V AC), 15 kA (230/400 V AC), UL interrupting rating up to 10 kA (60 V DC).
- Contact Configuration: 1P+N with right-positioned neutral terminals.
- Terminal Type: Screw terminals; connecting capacity flexible 0.75–25 mm², rigid up to 35 mm².
- Insulation & Dielectric Strength: Dielectric test voltage 2 kV at 50/60 Hz for 1 minute.
- Durability: Electrical and mechanical endurance 20,000 cycles each.
- Actuator: Toggle type with red ON/ green OFF indication, sealable and rated IP protection compliant.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the function of the System pro M compact S200M miniature circuit breakers?
The S200M miniature circuit breakers provide overload protection through a delayed thermal tripping mechanism and short circuit protection via an electromechanical tripping mechanism.
What are the available configurations for the S200M circuit breakers?
The S200M circuit breakers are available in configurations of 1P, 1P+N, 2P, 3P, 3P+N, and 4P.
What is the maximum breaking capacity of the S200M circuit breakers?
The S200M circuit breakers have a breaking capacity of up to 25 kA at 133 V AC and 15 kA at 230/400 V AC.
What is the rated current capacity of the S200M circuit breakers?
The rated current capacity of the S200M circuit breakers is up to 63A.
What type of terminal connections do the S200M circuit breakers use?
The S200M circuit breakers use screw terminals, with a connecting capacity of 0.75–25 mm² for flexible cables and up to 35 mm² for rigid cables.
Can auxiliary contacts be mounted on the S200M circuit breakers?
Yes, bottom-fitting auxiliary contacts can be mounted on the S200M to save 50% space.
What standards do the S200M circuit breakers comply with?
All MCBs in the S200M range comply with IEC/EN 60898-1 and IEC/EN 60947-2. See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CDS271103R0981 |
|---|---|
| Amperage | 0.5A |
| Number of Poles | 2 Pole |
| Manufacturer | ABB |
| Alternative Product SKU | S201M-D0.5NA |
| Barcode | 4016779600354 |
