ABB S201M-B63NA MCB - S200M - 2P - B - 63A
MPN: 2CDS271103R0635
Alt. SKU: S201M-B63NA
Special Price
£52.15
£43.46
Regular Price
£94.82
Why Choose the S201M-B63NA [2CDS271103R0635]
System pro M compact S200M miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 10 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200M comply with IEC/EN 60898-1 and IEC/EN 609 47-2, allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200M to save 50% space.
Technical Specification
- Function: Miniature circuit breaker with thermal and electromechanical tripping for overload and short-circuit protection.
- Rated Current: Up to 63 A.
- Voltage Ratings: 230/400 V AC; UL/CSA rated to 480Y/277 V AC and 60 V DC.
- Contact Configuration: 1P+N with position indication (Red ON / Green OFF).
- Breaking Capacity: Up to 25 kA at 133 V AC, 15 kA at 230/400 V AC.
- Terminal Type: Screw terminals with flexible and rigid conductor capacity from 0.75 to 35 mm².
- Mechanical and Electrical Endurance: 20,000 cycles mechanical, 10,000-20,000 AC cycles electrical.
- Dielectric Test Voltage: 2 kV at 50/60 Hz for 1 minute.
- Energy Limiting Class: Class 3.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the maximum rated current for the S200M miniature circuit breakers?
The maximum rated current is up to 63 A.
What are the available configurations for the S200M circuit breakers?
The S200M circuit breakers are available in configurations of 1P, 1P+N, 2P, 3P, 3P+N, and 4P.
What is the breaking capacity of the S200M circuit breakers?
The breaking capacity is up to 10 kA at 230/400 V AC and up to 25 kA at 133 V AC.
What type of tripping mechanisms do the S200M circuit breakers use?
They use a delayed thermal tripping mechanism for overload protection and an electromechanical tripping mechanism for short circuit protection.
What is the conductor capacity for the terminal type of the S200M?
The screw terminals can accommodate flexible and rigid conductors from 0.75 to 35 mm².
Are the S200M circuit breakers compliant with any standards?
Yes, they comply with IEC/EN 60898-1 and IEC/EN 609 47-2. See the manufacturer's data sheet for standards and approvals.
Can auxiliary contacts be mounted on the S200M circuit breakers?
Yes, bottom-fitting auxiliary contacts can be mounted to save 50% space.
| Manufacturer Part Number | 2CDS271103R0635 |
|---|---|
| Amperage | 63A |
| Number of Poles | 2 Pole |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
| Manufacturer | ABB |
| Alternative Product SKU | S201M-B63NA |
| Barcode | 4016779543842 |
