ABB S201-K1NA MCB - S200P - 1+NP - K - 1A
MPN: 2CDS251103R0217
Alt. SKU: S201-K1NA
Special Price
£54.20
£45.17
Regular Price
£98.54
Why Choose the S201-K1NA [2CDS251103R0217]
System pro M compact S200 miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 6 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200 comply with IEC/EN 60898-1, IEC/EN 60947-2, UL1077 allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200 to save 50% space.
Technical Specification
- Function: Current limiting miniature circuit breaker with thermal and electromechanic tripping for overload and short circuit protection.
- Voltage Rating: Up to 400 V AC, suitable for 230/400 V systems.
- Current Rating: Up to 63 A.
- Contact Configuration: 1P+N with right-positioned neutral terminal.
- Breaking Capacity: 10 kA at 230/400 V AC, 20 kA at 133 V AC, up to 20 kA DC ratings.
- Insulation/Test Voltage: Dielectric test voltage 2 kV at 50/60 Hz for 1 minute.
- Terminal Type: Failsafe bi-directional cylinder-lift screw terminals.
- Wire Capacity: Flexible 0.75–25 mm², rigid 0.75–35 mm², busbar 10/10 mm².
- Mechanical & Electrical Endurance: 20,000 cycles each.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What are the tripping mechanisms of the S200 miniature circuit breakers?
The S200 miniature circuit breakers feature a delayed thermal tripping mechanism for overload protection and an electromechanic tripping mechanism for short circuit protection.
What is the maximum breaking capacity of the S200 MCBs?
The S200 MCBs have a breaking capacity of up to 10 kA at 230/400 V AC and up to 20 kA at 133 V AC.
What is the wire capacity for the terminals of the S200?
The wire capacity for flexible wires is 0.75–25 mm², for rigid wires is 0.75–35 mm², and for busbars is 10/10 mm².
Can auxiliary contacts be mounted on the S200 MCBs?
Yes, bottom-fitting auxiliary contacts can be mounted on the S200 to save 50% space.
What is the rated current for the S200 miniature circuit breakers?
The S200 miniature circuit breakers are rated for currents up to 63 A.
Are the S200 MCBs compliant with any standards?
Yes, all MCBs of the S200 range comply with IEC/EN 60898-1, IEC/EN 60947-2, and UL1077. See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CDS251103R0217 |
|---|---|
| Amperage | 1A |
| Number of Poles | 1 Pole + N |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
| Manufacturer | ABB |
| Alternative Product SKU | S201-K1NA |
| Barcode | 4016779531832 |
