ABB S201-C2NA MCB - S200P - 1+NP - C - 2A
MPN: 2CDS251103R0024
Alt. SKU: S201-C2NA
Special Price
£33.31
£27.76
Regular Price
£60.56
Why Choose the S201-C2NA [2CDS251103R0024]
System pro M compact S200 miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 6 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200 comply with IEC/EN 60898-1, IEC/EN 60947-2, UL1077 allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200 to save 50% space.
Technical Specification
- Function: Miniature circuit breaker with thermal and electromechanic tripping for overload and short circuit protection.
- Voltage Ratings: Up to 480Y/277 V AC, 110 V DC.
- Current Rating: Rated currents up to 63 A.
- Contact Configuration: 1P+N with red ON / green OFF indication.
- Breaking Capacity: Ultimate short-circuit breaking capacity up to 20 kA (133 V AC), 10 kA (230/400 V AC).
- Terminal Type and Capacity: Screw terminals, supports flexible cables 0.75 to 25 mm² and rigid cables up to 35 mm².
- Mechanical and Electrical Endurance: 20,000 cycles each.
- Insulation and Dielectric Strength: Dielectric test voltage 2 kV (50/60 Hz, 1 min), insulation group II material.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the function of the System pro M compact S200 miniature circuit breakers?
They provide overload and short circuit protection using thermal and electromechanic tripping mechanisms.
What are the available configurations for the S200 MCBs?
The configurations include 1P, 1P+N, 2P, 3P, 3P+N, and 4P.
What is the maximum breaking capacity of the S200 MCBs?
The ultimate short-circuit breaking capacity is up to 20 kA at 133 V AC and 10 kA at 230/400 V AC.
What is the rated current capacity of the S200 MCBs?
They are rated for currents up to 63 A.
What type of cables can be connected to the S200 MCBs?
They support flexible cables from 0.75 to 25 mm² and rigid cables up to 35 mm².
Are the S200 MCBs compliant with any standards?
Yes, they comply with IEC/EN 60898-1, IEC/EN 60947-2, and UL1077. See the manufacturer's data sheet for standards and approvals.
How can auxiliary contacts be mounted on the S200 MCBs?
A bottom-fitting auxiliary contact can be mounted to save 50% space.
| Manufacturer Part Number | 2CDS251103R0024 |
|---|---|
| Amperage | 2A |
| Number of Poles | 1 Pole + N |
| Country of Manufacture | Germany |
| Manufacturer | ABB |
| Alternative Product SKU | S201-C2NA |
| Barcode | 4016779531696 |
