ABB s201-b40 sp mcb b40a 6ka
MPN: 2CDS251001R0405
Alt. SKU: S201-B40
Special Price
£12.50
£10.42
Regular Price
£22.73
Why Choose the S201-B40 [2CDS251001R0405]
System pro M compact S200 miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 6 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200 comply with IEC/EN 60898-1, IEC/EN 60947-2, UL1077 allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200 to save 50% space.
Technical Specification
- Function: Miniature circuit breaker with thermal overload and electromechanic short circuit trip mechanisms.
- Rated Current: Up to 63 A.
- Voltage Rating: Up to 400 V AC, 60 V DC.
- Contact Configuration: 1 Pole (1P).
- Breaking Capacity: Up to 20 kA (133 V AC), 10 kA (230/400 V AC), 20 kA (24 V DC), 10 kA (60 V DC).
- Insulation and Dielectric Strength: Dielectric test voltage 2 kV (50/60 Hz, 1 min).
- Terminal Type and Capacity: Screw terminals; busbar 10/10 mm², flexible and rigid conductors 0.75–35 mm².
- Mechanical Durability: 20,000 operations.
- Electrical Endurance: 10,000 AC cycles.
- Actuator: Toggle type, sealable, with red ON/green OFF indication.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What are the tripping mechanisms of the S200 miniature circuit breakers?
The S200 miniature circuit breakers feature a delayed thermal tripping mechanism for overload protection and an electromechanic tripping mechanism for short circuit protection.
What is the maximum breaking capacity of the S200 circuit breakers?
The S200 circuit breakers have a breaking capacity of up to 6 kA at 230/400 V AC.
What configurations are available for the S200 circuit breakers?
The S200 circuit breakers are available in various configurations including 1P, 1P+N, 2P, 3P, 3P+N, and 4P.
What is the rated current for the S200 circuit breakers?
The rated current for the S200 circuit breakers is up to 63 A.
Can auxiliary contacts be mounted on the S200 circuit breakers?
Yes, bottom-fitting auxiliary contacts can be mounted on the S200 to save 50% space.
What are the terminal types and capacities for the S200 circuit breakers?
The S200 circuit breakers have screw terminals with a busbar capacity of 10/10 mm² and can accommodate flexible and rigid conductors from 0.75 to 35 mm².
What standards do the S200 circuit breakers comply with?
All S200 circuit breakers comply with IEC/EN 60898-1, IEC/EN 60947-2, and UL1077. See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CDS251001R0405 |
|---|---|
| Amperage | 40A |
| Number of Poles | 1 Pole |
| Trip Curve Type | Type B 10KA |
| Manufacturer | ABB |
| Alternative Product SKU | S201-B40 |
| Barcode | 4016779465403 |
| Product Lead Time | Estimated delivery time 3-4 days |
